Triumph Thruxton Ace Special Edition

.

Make Model

Triumph Thruxton Ace Cafe Special Edition

Year

2015

Engine

Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder

Capacity

865 cc / 52.8 cub in.
Bore x Stroke 90 x 68 mm
Cooling System Air-cooled
Compression Ratio 9.2:1
Lubrication Wet sump
Engine Oil Synthetic, 15W/50
Oil Capacity 4.5 L / 1.2 US gal / 1.0 Imp gal

Induction

Multipoint Sequential Fuel injection

Ignition

Digital
Spark Plug NGK, DPR8EA-9
Starting Electric

Max Power

50.7 kW / 68 hp @ 7400 rpm

Max Torque

68 Nm / 6.93 kgf-m / 50.2 ft-lb @ 5800 rpm
Clutch Wet, multi-plate

Transmission

5 Speed
Final Drive Chain, X-ring
Frame Tubular steel cradle, swingarm twin-sided, tubular steel

Front Suspension

41 mm Forks with adjustable preload
Front Wheel Travel 120 mm / 4.7 in

Rear Suspension

Chromed spring twin shocks with adjustable preload
Rear Wheel Travel 106 mm / 4.1 in

Front Brakes

Single 320mm disc, Nissin 2 piston floating caliper

Rear Brakes

Single 255mm disc, Nissin 2 piston floating caliper
Wheels Front 36-spoke, 18 x 2.5 in
Wheels Rear 40-spoke, 17 x 3.5 in

Front Tyre

100/90 R18

Rear Tyre

130/80 R17
Rake 26°
Trail 97 mm / 3.8 in
Dimensions Length 2150 mm / 84.6 in
Width     830 mm / 32.7 in (with handlebars)
Height  1095 mm / 43.1 in (without mirrors)
Wheelbase 1490 mm / 58.7 in
Seat Height 820 mm / 32.2 in

Dry Weight

214 kg / 472 lbs
Wet Weight 230 kg / 507.06 lbs

Fuel Capacity

16 Litres / 4.2 US gal / 3.5 Imp gal

Consumption Average

@ 120 km/h / 75 mph: 4.2 L/100 km / 23.8 km/l / 56 US mpg / 67 Imp gal

Colours

Phantom black, Brooklands green



Triumph has revealed this special edition version of the Thruxton called the Ace which celebrates the link between the British manufacturer and the famous London café so synonymous with motorcycle history.

The Ace gets a unique black and white paintjob, ‘Oxblood’ custom seat, bar-end mirrors, a handlebar plaque and officially sanctioned Ace Café logos and comes with the usual wire wheels and 865cc parallel-twin engine.

Triumph’s press release states: “With low slung handlebars, alloy-rimmed wire wheels and a central racing stripe running along the tank to the beautifully sculpted custom seat, the Triumph Thruxton Ace looks as if it would be equally at home on a classic race grid as outside the local café after a spirited morning ride.

Featuring the same engine as the renowned Triumph Thruxton, power is provided by Triumph’s 865cc signature parallel twin from the Bonneville. Producing peak power of 69PS and 69Nm of torque across a broad rev range, the Thruxton delivers its performance with a suitable increase in the edginess of the exhaust note from the classically styled chrome silencers.

The Thruxton Ace’s chassis is based around the Bonneville, and meets Triumph’s exacting standards by generating an assured, composed, yet agile ride at all times. Its steel tube frame, 41mm KYB forks, twin KYB rear shocks, Nissin disc brakes and wire spokes merge modern engineering with retro style to create a perfectly balanced bike. The deceptively sporty steering geometry gives the Thruxton Ace performance to match the engine’s unique character and progressive riding position.”

It was the London truckers' cafe that became a favourite haunt of Britain's bikers and a powerful symbol of post-war counterculture. The Ace Cafe gained notoriety as the biker hang-out in the early 60's and formed an instrumental piece of the cafe racer culture of the era. The new Thruxton Ace celebrates the rich association of Triumph's history with the Ace Cafe.

The Thruxton Ace combines the evocative silhouette of a true Triumph classic racer, with a fabulous one-off Pure White and Jet Black paint livery reflecting Triumph's long historical connection with the Ace Cafe. The bike is tastefully co-branded with Ace Cafe logos adorning the side panels, tank and tail section.

With low slung handlebars, alloy-rimmed wire wheels and dominating central racing stripe running along the tank to the beautifully sculpted custom seat, the Triumph Thruxton Ace looks as ready to take pole position on a classic race grid as much as sit purposefully outside the local cafe after a spirited morning ride.

Featuring the same engine as the renowned Triumph Thruxton, power is provided by Triumph's signature charismatic parallel twin from the Bonneville. Producing peak power of 69PS and 69Nm of torque across a broad rev range, the Thruxton delivers its performance with a suitable increase in the edginess of the exhaust note form the classically styled chrome silencers.

The Truxton's chassis is based around the Bonneville, and meets Triumph's exacting standards by generating an assured, composed, yet agile ride at all times. Its steel tube frame, 41mm KYB forks, twin KYB rear shocks, Nissin disc brakes and wire spokes on lightweight aluminium rims running the latest radial tyres combine with sporting steering geometry to give the Thruxton Ace performance to match the engine's character and riding position.

The Thruxton Ace. An everyday icon.

Performance

The café racers were built to perform, not just to look good.

Today, this 865cc parallel twin puts out a healthy 69PS with 69Nm of torque at its peak, with plenty available at low revs so you get most use out of it.

Fuelling is controlled by a sophisticated computer programmed management system for clean emissions and a smooth, predictable throttle response.

Configuration

The basic format is the same as the current Bonneville, with 360 degree firing intervals, double overhead cams, eight valves, twin balance shafts and fuel injection. So you know it's a thoroughly modern engine that, despite its convincing old-school looks, easily meeting Triumph’s high standard of reliability, durability and efficiency.
Sound

It's the sound and feel of the engine that matters, from the thumping thrust of the generous low rev torque to the eager high revs and the purring, even exhaust note. So distinctive to the parallel twin.

Frame

All of our extensive chassis experience and technology has gone into the Thruxton Ace Cafe SE’s simple tubular steel construction. Providing easy, neutral steering and exceptional balance even at low speeds.

Suspension

We fitted 41mm forks and chromed rear shocks and retuned them for a firmer ride and tighter control in high speed corners. The shocks include adjustability for spring preload for carrying a passenger or to suit your riding style.

Brakes

We fitted the front with a big 320mm single disc strong enough to match the sporting pedigree of the Thruxton Ace Cafe SE with plenty of feedback to enhance your ride. Yet we've made it as unobtrusive as possible within the 1960s styling.

At the rear is another disc, so there’s no compromise in the Thruxton Ace Cafe SE's thoroughly modern braking performance.

Wheels and Tyres

The wheels are wire-spoked with aluminium alloy rims, 18 inches at the front and 17 inches rear for the classic café racer look. They're lightweight too, for increased suspension performance and handling agility.

Handling

We kept the geometry similar to the Bonneville's but with a little less trail at 97mm so you get sharper steering and more urgent handling when ridden hard. But the same neutral, obedient feel during less exuberant riding, making the Thruxton Ace Cafe SE a rewarding as well as an easy bike to ride.

Riding Position

Pure 1960s café racer but not at the expense of comfort, that's what the Thruxton Ace Cafe SE is all about. So there's a sporty forward lean that makes you look the part. The footrests have been raised and set back to complement the bar position, so you are close to the bike and can really feel how the front end is performing.

We’ve positioned the bar end mirrors to work best when you are tucked down and forward, providing a good view of the road behind around elbows and body.

But none of this is so extreme that it spoils the feeling of versatility. You can still tour or commute on the Thruxton Ace Cafe SE as well as take it for a sunny Sunday burn.
