Triumph TR6R 650 Trophy Sport

.

Make Model

Triumph TR6R 650 Trophy Sport

Year

1968 -

Engine

Four stroke, parallel twin cylinder, OHV

Capacity

649 cc / 40 cu-in
Bore x Stroke 71 x 82 mm
Compression Ratio 9.0:1
Cooling System Air cooled

Induction

30 mm Amal concentric carburetor

Ignition

Battery and coil

Starting

Electric

Max Power

32 kW / 43 hp @ 6500 rpm
Clutch Wet, multi-plate, cable operated

Transmission

4 Speed constant mesh

Final Drive

Chain

Gear Ratios

1st 11.80 / 2nd 8.17 / 3rd 5.76 / 4th 4.84

Frame

Brazed lug, full cradle, single downtube

Front Suspension

Telescopic fork, hydraulic damping

Rear Suspension

Swingarm, 2 x Girling dampers

Front Brakes

8 in Drum

Rear Brakes

7 in Drum

Front Tyre

3.25 x 19

Rear Tyre

4.00 x 18
Wheelbase 1397 mm / 55 in
Seat Height 793 mm / 31.2 in

Ground Clearance

152 mm / 6.0 in

Wet Weight

177 kg / 390 lbs

Fuel Capacity

13.2 Litres / 3.5 US gal
.
