Triumph Bonneville

Make Model	Triumph Bonneville
Year	2007
Engine	Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder
Capacity	865 cc / 52.8 cu in
Bore x Stroke	90 x 68 mm
Cooling System	Air-cooled
Compression Ratio	9.2:1
Lubrication	Wet sump
Engine Oil	Synthetic, 15W/50
Induction	Multipoint Sequential Fuel injection
Ignition	Digital
Max Power	49 kW / 66 hp @ 7250 rpm
Max Torque	71 Nm / 7.24 kgf-m / 52 ft-lb @ 6000 rpm
Clutch	Wet, multi plate
Transmission	5 Speed
Final Drive	Chain, X-ring
Frame	Tubular steel cradle, swing arm: twin-sided, tubular steel
Front Suspension	41mm Kayaba telescopic forks
Front Wheel Travel	120 mm / 4.7 in
Rear Suspension	Kayaba chrome spring twin shocks with adjustable preload
Rear Wheel Travel	106 mm / 4.17 in
Front Brakes	Single 310 mm disc, 2 piston calipers
Rear Brakes	Single 255 mm disc, 2 piston calipers
Wheels Front	36 Spokes, 19 x 2.5 in
Wheels Rear	36 Spokes, 17 x 3.5 in
Front Tyre	100/90 19
Rear Tyre	130/80 17
Rake	28°
Trail	110 mm / 4.3 in
Dimensions	Length 2230 mm / 87.8 in Width 840 mm / 33.1 in Height 1100 mm / 43.3 in
Wheelbase	1500 mm / 59.1 in
Seat Height	775 mm / 30.5 in
Dry Weight	205 kg / 451 lbs
Wet Weight	226 kg / 499 lbs
Fuel Capacity	16.6 Litres / 4.4 US gal / 3.7 Imp gal

A true roadster in every sense of the word, the Bonneville matches classic British style to 21st century technology. This pairing of authenticity with modernity has led the Bonneville to become an icon in its own right; world famous designer Paul Smith personally designed a signature series of Bonnies, with accessories to match. Our sixty8 range, which includes hand crafted laptop bags, iPod holders and a series of unique custom-painted tank covers, are all useful and stylish additions.

For 2007 the Bonneville has an increased engine size of 865cc. This latest model also comes with a black engine and polished, lacquered engine covers and a span adjustment clutch lever.

The Bonneville has excellent road manners and great agility in jammed city streets. The Bonneville’s road holding, handling and stopping ability is crisp, composed and confidence inspiring. The braking set-up of single front 310mm disc and 255mm rear, both worked on by powerful twin-piston calipers offers sensitivity and control.

The Bonneville’s a great way to cover the urban landscape and equally at home blatting down a leafy country lane on a Sunday ride out.

Why not go along to your Triumph dealer and test ride a true icon?

AUTHENTICITY WITH MODERNITY

A true roadster in every sense of the word, the Bonneville matches classic British style to 21st century technology. This pairing of authenticity with modernity has led the Bonneville to become an icon in its own right; world famous (and quintessentially British) designer Paul Smith has personally designed a signature series of Bonnies, with accessories to match. Triumph’s own sixty8 range, which includes hand crafted laptop bags, iPod holders and a series of unique custom-painted tank covers, further enhances the Bonneville’s status not only as a motorcycle but also as a cool style statement.

For 2007, the Bonneville receives the following changes:

• Increased engine capacity from 790cc to 865cc
• Black engine with polished and lacquered covers
• Adjustable clutch lever
