Suzuki GSX-R 750WR SP

.

Make Model

Suzuki GSX-R 750WR SP

Year

1994

Engine

Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.

Capacity

749 c / 45.7 cub. in.

Bore x Stroke

70 x 48.7 mm

Compression Ratio

11.8:1

Cooling System

Liquid cooled

Engine Oil

Synthetic,10W/40

Exhaust System

4-into-2-into-1 Stainless-steel exhaust

Lubrication

Wet sump

Induction

4 x TRM40 carburetors

Ignition

Computer controlled electronic ignition

Spark Plug

NGK, CR9EK

Battery

8 Amp/hour

Starting

Electric

Max Power

83.5 kW / 112 hp @ 10500 rpm

Max Torque

75 Nm / 7.6 kgf-m / 55.3 ft-lb @ 1000 rpm

Clutch

Cable operated, wet multiple, coil spring

Transmission

6 Speed, constant mesh
Final Drive #530 Chain, O-ring sealed, 108 links
Gear Ratios 1st 2.87 / 2nd 2.06 / 3rd 1.65 / 4th 1.43 / 5th 1.26 / 6th 1.12:1
Frame 5-sided aluminium pipe frame with sand-casted steering head section and cast swing arm pivot

Front Suspension

Showa 43 mm cartridge style upside-down forks, preload, compression and rebound adjustable

Front Wheel Travel

120 mm / 4.7 in.

Rear Suspension

Full floater, preload, compression and rebound adjustable

Front Brakes

2 x 310 mm Discs, 6 piston Nissin calipers

Rear   Brakes

Single 280 mm disc, 2 piston Nissin caliper

Wheels

Alloy, 3 spoke

Front Rim

3.5 x 17

Front Tyre

120/70 ZR17

Rear Rim

5.5 x 17

Rear Tyre

180/55 ZR17
Rake 24.5°
Trail 94 mm / 3.7 in.
Wheelbase 1440 mm / 56.7 in.

Dimensions

Length  2095 mm / 82.5 in.

Width      730 mm / 28.7 in.

Height   1135 mm / 44.7 in.

Seat Height

795 mm / 31.3

Dry Weight

199 kg / 438.6 lbs

Wet Weight

229.5 kg / 506 lbs.

Fuel Capacity

21 Litres / 5.5 US gal / 4.6 Imp gal

Average Consumption

6.3 l/100 km / 15.8 km/l / 37.2 US mpg / 44.8 Imp mpg

Braking 100kmh - 0 / 60 mph - 0

36.7 m / 120.4 ft

Braking 60 kmh - 0 / 37 mph - 0

12.9 m / 42.3 ft

Standing ¼ mile

11.16 sec / 199 km/h / 124 mph

Top Speed

246 km/h / 153 mph
