Suzuki GSX-R 250

.

Make Model

Suzuki GSX-R250

Year

1987

Engine

Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder

Capacity

248 cc / 15.1 cu in
Bore x Stroke 49 x 33 mm
Compression Ratio 12.5:1
Cooling System Liquid cooled
Lubrication System Wet sump

Induction

Single carburetor

Ignition

Transistor

Starting

Electric

Max Power

33.6 kW / 45 hp @ 14000 rpm

Max Torque

24 Nm / 2.5 kgf-m /17.7 lb-ft @ 10500 rpm

Clutch

Wet, multi-plate, cable operated

Transmission

6 Speed

Final Drive

Chain

Frame

Steel, twin spar

Front Suspension

Telescopic forks

Rear Suspension

Full floater

Front Brakes

2 x 300 mm Discs, 2 piston calipers

Rear Brakes

Single 240mm disc, 1 piston caliper

Front Wheel

2.50 - 17

Rear Wheel

3.50 - 17
Front Tyre 110/80-R17
Rear Tyre 130/70-R17
Rake 26o
Trail 103 mm / 4.1 in
Dimensions Length: 2000 mm / 78.7 in
Width:    700 mm / 27.6 in
Height:  1105 mm / 43.5 in
Wheelbase 1370 mm / 53.9 in
Ground Clearance 125 mm / 4.9 in
Seat Height 770 mm / 30.3 in

Dry Weight

138 kg / 304 lbs

Fuel Capacity

16 Litres / 4.2 US gal / 3.5 Imp gal

Top Speed

180 km/h / 112 mph

A couple of years after the presentation of the GSX-R750 a little brother with a 250cc engine was born. Like its big brother, the GSX-R250 had a box-frame (steel, not aluminum), full fairing, full-floater rear swing and a four-cylinder four-stroke engine. But while the GSX-R750 engine was air and oil-cooled, the baby brother had a liquid-cooled engine. Not many examples are seen outside Japan. 17-inch cast wheels and 300 mm twin disc brake at the front.
