Suzuki GSX-S 750

.

Make Model

Suzuki GSX-S 750

Year

2017 - 18

Engine

Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder, TSCC

Capacity

749 cc / 45.7 cub. in

Bore x Stroke

72.0 x 46.0 mm

Compression Ratio

12.3:1

Cooling System

Liquid cooled

Lubrication

Wet sump

Induction

Suzuki Fuel Injection with SDTV

Ignition

Electronic ignition (transistorised)

Traction Control

Suzuki Advanced Traction Control

Starting

Electric

Max Power

73.8 kW / 99.1 hp @ 10170 rpm

Max Torque

73.6 Nm / 54.3 lb-ft / @ 9060 rpm

Clutch

Wet, multi-plate type

Transmission

6 Speed, constant mesh

Final Drive

Chain, DID50VAZ, 114 links

Frame

Aluminium, twin spar

Front Suspension

Inverted telescopic, coil spring, oil damped

Front Wheel Travel

120 mm / 4.7 in

Rear Suspension

Link type, coil spring, oil damped, 7-way adjustable

Rear Wheel Travel

130 mm / 5.1 in

Front Brakes

2x 310 mm Full floating discs, 4-piston calipers

Rear Brakes

Single 220 mm disc, Nissin, 1-piston caliper

Front Tyre

120/70ZR17M/C (58W), tubeless

Rear Tyre

180/55ZR17M/C (73W), tubeless

Dimensions

Length 2125 mm / 83.6 in
Width    785 mm / 30.9 in
Height 1055 mm / 41.5 in

Wheelbase

1455 mm / 57.2 in

Seat Height

820 mm / 32.2 in

Ground Clearance

135 mm / 5.1 in

Wet Weight

213 kg / 469.6 lbs

Fuel Capacity

16 Litres / 4.2 US gal / 3.7 Imp gal

.

Suzuki continues to roll out improvements and updates to its line of standard-class streetbikes, and now announces the 2018 Suzuki GSX-S750 and GSX-S750Z to go along with the 2017 GSX-S1000/F. Featuring significant engine and chassis advancements, these performance-focused street bikes deliver the energetic power that could only come from the GSX-R lineage. Suzuki offers this 750 in two striking styles, the original GSX-S750 and the GSX-S750Z which features Suzuki’s Anti-lock Brake System and dramatic matte black body work.



2018 GSX-S750 & GSX-S750Z


The new 2018 GSX-S750 brings significant engine and chassis advancement over the prior version to firmly establish itself as the second model in Suzuki’s innovative lineup of performance street machines. As with the GSX-S1000, this new GSX-S750 inherits its heart and soul from the 30-year racing heritage of the GSX-R750. With boosted engine power and a suite of new rider-friendly features, this restyled GSX-S750 is ready to capture hearts and turn heads as the new leader in its class.



With styling influenced by its bigger stablemate, but with its own aggressive turn, the GSX-S750 new bodywork looks wild and forceful, yet keeps the rider comfortable at all times. The new headlight nacelle houses provides a visual focal point while the under cowl connects the chassis styling to the engine and new exhaust system.



Nestled in the headlight nacelle like the GSX-S1000, the new lightweight and compact instrument panel uses a LCD display that includes speedometer, tachometer, odometer, dual tripmeters, a clock and a variety of other functions that can be controlled via the rocker switch on the left-hand handlebar. Below the panel are new, large-diameter, matter-black tapered handlebars that damp vibration while adding style and good control leverage for the rider.

The potent 749cc 4-cylinder fuel-injected engine uses 2005 GSX-R750 architecture so the power delivery is an excellent bled of strong low-end and a muscular top end. This also permits a shorter chassis which greatly enhances handling and makes the GSX-S750 the only motorcycle in its class with an engine with SuperSport lineage.



Suzuki’s advanced traction control system lets the GSX-S750 rider control the throttle with more confidence in various riding conditions. As a result, the rider can enjoy sport riding with less anxiety. There are four traction control modes (1, 2, 3, and OFF) that the rider can easily adjust at rest or on-the-fly via a handlebar-mounted control. The difference between the modes are their sensitivity to road conditions.



This new GSX-S750 is equipped with Suzuki’s Easy-start System that requires just a simple touch of the starter button to fire up the engine (without pulling the clutch lever if the transmission is in neutral).  Suzuki’s patented, Throttle-body Integrated Idle Speed Control (TI-ISC) stabilizes the engine idle speed and includes Suzuki’s Low RPM Assist feature that seamlessly adjusts engine speed during take-off and low-speed riding to smooth the power delivery and to help reduce the possibility of the rider stalling the motorcycle.



The unique chassis integrates the best qualities of a tubular girder streetbike frame and a twin-spar sportbike frame with a new trapezoidal, beam-type swingarm that tapers down to new chain adjusters adding strength and style.  Controlling the road is a KYB pre-load adjustable shock and inverted fork with gold anodized outer tubes. Radially mounted to the fork are new, four-piston Nissin Monobloc brake calipers squeezing twin, 310mm wave style brake rotors with a single-piston caliper and wave-rotor out back to help deliver controlled stops.



For an additional injection of technology and style, there’s the GSX-S750Z. This bike includes the Suzuki Anti-lock Brake System plus aggressive blacked-out styling that surrounds the ergonomically comfortable, yet sporty riding position.



Choosing the GSX-S750, or the dark personality of the GSX-S750Z delivers discriminating riders the perfect sportbike balance of engine punch, chassis response, great looks and smart value. This new GSX-S750 looks better and outperforms its popular predecessor – and other entries in the class. It is nimble, comfortable, and an exhilarating, fun ride.

Engine Features

Potent 749cc 4-cylinder fuel-injected engine uses 2005 GSX-R750 architecture so the power delivery is an excellent bled of strong low-end and a muscular top end.
Using the K5 generation GSX-R engine architecture also permits a shorter chassis which greatly enhances handling. This also makes the GSX-S750 the only motorcycle in its class with an engine with SuperSport lineage.


Ventilation holes are added to the bottom side of each cylinder in the GSX-S750’s crankcase. The holes reduce pumping loss to help produce power and gain fuel economy.


Camshafts tuned specifically for the GSX-S750 deliver a dynamic wave of smooth torque and strong acceleration.

Throttle bodies with Suzuki Dual Throttle Valve (SDTV) system contribute to better throttle response and torque at the low-to-mid RPM range, while still producing peak performance.  New, ten-hole, long-nose fuel injectors deliver finer atomized fuel to increase combustion efficiency.



Suzuki’s patented, Throttle-body Integrated Idle Speed Control (TI-ISC) stabilizes the engine idle speed and helps lower emissions. The system is compact and lightweight.


The TI-ISC on the GSX-S750 has Suzuki’s Low RPM Assist feature that seamlessly adjusts engine speed during take-off and low-speed riding to smooth the power delivery and to help reduce the possibility of the rider stalling the motorcycle.


 A new, larger capacity air box is required to match the higher engine output. The air inlets have been designed to provide an exciting auditory experience.

The Engine Control Module (ECM) provides state-of-the-art engine management and has enhanced settings to suit the intake and exhaust systems, resulting in linear throttle response and class-leading fuel economy.


Suzuki’s advanced traction control system* lets the GSX-S750 rider control the throttle with more confidence in various riding conditions. As a result, the rider can enjoy sport riding with less anxiety. There are four traction control modes (1, 2, 3, and OFF) that the rider can easily adjust at rest or on-the-fly via a handlebar-mounted control. The difference between the modes are their sensitivity to road conditions.



- Mode 1 is lowest sensitivity level most suitable for skilled riders or in conditions that have good road surface grip (sport riding on good, smooth roads).
- Mode 2 is a moderate sensitivity level that is suitable for most riders or in conditions that have varied road surface grip (city riding, regular road conditions).
- Mode 3 is highest sensitivity level suitable for road conditions where the grip may be limited (wet or cold surfaces).
- OFF disengages all traction control features.

The digital ignition fires iridium type spark plugs that increase spark strength and combustion efficiency, contributing to higher power, more linear throttle response, easier engine start-up, and a more stable idle. These quality components also last longer than conventional spark plugs.
The fresh-design stainless-steel, 4-2-1 exhaust system helps the engine deliver a strong low-to-mid range punch with an exciting rush to redline. A larger catalyzer is in the mid-pipe to assist in emissions control without sacrificing performance.

Angular radiator shrouds efficiently guide cooling air to the high-capacity radiator. Additional heat is removed from the engine via the use of a lightweight and compact liquid-cooled oil cooler (like those used on GSX-R models).


Transmission Features


The race-proven six-speed close-ratio transmission features vertically staggered shafts to reduce overall engine length.
The shorter final gear ratio enables the new GSX-S750 accelerate quicker than the prior model while the additional engine power maintains the same top speed potential.


Large diameter, wet multi-plate clutch is derived from a GSX-R750 design to easily transmit power while the rack and pinion clutch release provides the rider with superb friction-point feel.


The refined shift linkage helps the rider easily and quickly select the best gear for the riding conditions.


The strong drive chain uses O-rings to preserve internal lubrication so power is transmitted smoothly and quietly.


Chassis Features

With styling influenced by the GSX-S1000, but with its own aggressive turn, the GSX-S750’s new bodywork looks wild and forceful, yet keeps the rider comfortable at all times.


The new headlight nacelle houses provides a visual focal point while the under cowl connects the chassis styling to the engine and new exhaust system.
Frame design combines the advantages of a compact tubular-style street bike frame and a twin-spar sportbike frame to deliver a dynamic ride. A reasonable sport riding position is created by a carefully crafted relationship between the handlebars, footrests and seat.



New, large-diameter, matter-black tapered handlebars damp vibration while adding style and good control leverage for the rider.
The low seat height of 820 mm (32.2 in.) contributes to the sporty, yet upright riding position and aids rider confidence at stops.
New, four-piston Nissin Monobloc brake calipers squeeze twin, 310mm wave style brake rotors up front with a single-piston rear caliper out back to help deliver controlled stops.



New inverted, gold-anodized KYB fork features a spring preload-adjustable design which provides a solid foundation for the new, radial mount brake calipers.
New, trapezoidal, beam-type swingarm tapers down to new chain adjusters adding strength and style.


Link-type rear suspension, with a single shock absorber working through a progressive linkage, has 7-way adjustable spring preload.

Newly designed, 10-spoke cast aluminum wheels from TPR hold Bridgestone Battleax Hypersport S21 radial tires that deliver increased grip and stability.
New, black finish, aluminum hand and foot controls provide excellent action and contribute to the motorcycle’s sporty style.


Electrical Features

This new GSX-S750 is equipped with Suzuki’s Easy-start System that requires just a simple touch of the starter button to fire up the engine (without pulling the clutch lever if the transmission is in neutral).
Distinctively shaped headlight nacelle contains a bright 60/55W H4 halogen bulb. The tail section houses an integrated LED taillight with a dual-pane, red/clear lens.

Similar to the GSX-S1000, the new lightweight and compact instrument panel uses a LCD display that includes speedometer, tachometer, odometer, dual tripmeters, gear position, coolant temperatures, driving range, average fuel consumption, instantaneous fuel consumption, traction control, and a clock functions.


The display has an adjustable intensity, white-color backlight for great nighttime visibility and is flanked by LED indicators for the turn signals, high beam, malfunction, traction control, ABS, plus coolant temperature and oil pressure alerts.
A three-phase charging system, with an oil-cooled stator, keeps the maintenance-free battery up to charge for trouble-free operation.


Additional Features

A variety of Genuine Suzuki Accessories are available for the GSX-S750, such as a solo seat cowl and sport screen, plus a large selection of logo apparel.
12-month unlimited mileage, limited warranty. Coverage length can be increased and benefits added via Suzuki Extended Protection.


The Traction Control System is not a substitute for the rider’s throttle control. It cannot prevent loss of traction due to excessive speed when the rider enters a turn and/or applies the brakes. Neither can it prevent the front wheel from losing grip.
