MV Agusta Dragster 800RC SCS |
|
Make Model |
MV Agusta Dragster 800RC SCS |
|
Year |
2021 |
|
Engine |
Four stroke, transverse three cylinder, DOHC with mechanical chain tensioner and DLC tappet, 4 valves per cylinder |
|
Capacity |
798 cc / 48.68 cu-in |
| Bore x Stroke | 79 x 54.3 mm |
| Cooling System | Cooling with separated liquid and oil radiators |
| Compression Ratio | 13.3:1 |
| Engine management system | Integrated ignition - injection system MVICS 2.1 (Motor & Vehicle Integrated Control System) with six injectors. Engine control unit Eldor Nemo 2.1, throttle body full ride by wire Mikuni, pencil-coil with ion-sensing technology, control of detonation and misfire. Torque control with four maps. Traction Control with eight levels of intervention with lean angle sensor |
| Electronic Quick-Shift | MV EAS 3.0 (Electronically Assisted Shift up & down) |
| Environmental Standard | Euro 5 |
|
Ignition |
Multipoint electronic injection |
| Starting | Electric |
|
Max Power |
103 kW / 140 hp @ 12300 rpm |
|
Max Torque |
87 Nm / 64.1 lb-ft @ 10250 rpm |
| Electronic Quick-shift | MV EAS 2.0 (Electronically Assisted Shift up & down) |
| Clutch | S.C.S. 2.0 (Smart Clutch System) Radius CX automatic clutch with hydraulic clutch actuation, wet multi-disc |
|
Transmission |
Cassette style, 6 speed, constant mesh |
| Final Drive | Chain |
| Primary Drive Ratio | 22/41 |
| Final Drive Ratio | 16/41 |
| Gear Ratio | 1st 13/37 2nd 16/34 3rd 18/32 4th 19/30 5th 21/30 6th 22/29 |
| Frame | ALS Steel tubular trellis, aluminium alloy rear swing arm pivot plates |
|
Front Suspension |
43mm Marzocchi USD aluminium telescopic hydraulic fork with DLC treated aluminium, with anodized fork legs and having rebound-compression damping and spring preload external and separate adjustment |
| Front Wheel Travel | 125 mm / 4.9 in |
|
Rear Suspension |
Progressive Sachs, single shock absorber with rebound and compression damping and spring preload adjustment, aluminium alloy single sided swing arm |
| Rear Wheel Travel | 130 mm / 5.1 in |
|
Front Brakes |
2x 320mm floating discs, with steel braking disc and flange, Brembo radial-type with 4 piston calipers |
|
Rear Brakes |
Single 220mm disc, Brembo 2 piston caliper |
| ABS | Continental MK100 with RLM (Rear Wheel Lift-up Mitigation) and with cornering function |
| Rim Front | Forged aluminium alloy 3.50 x 17 in |
| Rim Rear | Forged aluminium alloy 6.00 x 17 in |
|
Front Tyre |
120/70- ZR 17 M/C (58 W) |
|
Rear Tyre |
200/55- ZR 17 M/C (78 W) |
| Trail | 103.5 mm / 4.07 in |
| Steering Damper | Manually adjustable with 8 settings |
| Dimensions |
Length: 2035 mm / 80.1 in Width: 935 mm / 36.8 in |
| Wheelbase | 1400 mm / 55.1 in |
| Seat Height | 845 mm / 33.3 in |
| Ground Clearance | 135 mm / 5.3 in |
|
Dry Weight |
168 kg / 370.38 lbs 160 kg / 352.74 lbs - Rascing Kit with SC Exhaust and dedicated ECU Map version |
|
Fuel Capacity |
16.5 Litres / US 4.36 gal |
| Exclusive Features | MV Ride App - Cruise control Launch control - Certificate of origin - Limited Edition, Carbon Fiber Components: Rh/Lh front mudguard support brackets Fuel tank side covers - Rear fender |
| Optional | Racing Kit: SC-Project Titanium exhaust silencer + Power unit for SC exhaust silencer carry-over (with special mapping) |
|
Any corrections or more information on these motorcycles will be kindly appreciated. |
