Kawasaki ZX-6RR

.

Make Model

Kawasaki ZX-6RR

Year

2003

Engine

Four stroke, transverse four cylinder, DOHC, 4 valves per cylinder.

Capacity

599 cc / 36.6 cub in
Bore x Stroke 67 x 42.5 mm
Compression Ratio 13.0:1
Cooling System Liquid cooled,

Induction

Fuel injection with 38mm throttle bodies
Lubrication Wet sump

Ignition

Digital
Starting Electric

Max Power

86.8 kW / 118 hp @ 13200 rpm

Max Torque

64.4 Nm / 6.6 kgf-m / 47.5 lb-ft @ 12000 rpm
Clutch Wet, multiple discs, cable operated

Transmission

6 Speed
Final Drive Chain
Gear Ratios 1st 2.92 / 2nd 2.06 / 3rd 1.72 / 4th 1.45 / 5th 1.27 / 6th 1.15:1
Frame Perimeter, pressed-aluminium

Front Suspension

41mm inverted cartridge fork with adjustable preload, stepless rebound and compression damping and top-out springs
Front Wheel Travel 119 mm / 4.7 in

Rear Suspension

Bottom-Link Uni-Trak with gas charged shock, stepless rebound and compression damping, spring preload adjustability and top-out springs
Rear Wheel Travel 133 mm / 5.2 in

Front Brakes

2 x 280mm discs, 4 piston calipers

Rear Brakes

Single 220mm disc, 1 piston caliper

Front Tyre

120/65 ZR17

Rear Tyre

180/55 ZR17
Rake 25°
Trail 85 mm / 3.3 in.
Dimensions Length 2075 mm / 81.7 in
Width 714 mm / 28.1 in
Height  1120 mm / 44.1 in
Wheelbase 1400 mm / 55.1 in.
Seat Height  820 mm  /  32.3 in.

Dry-Weight

161 kg / 355 lbs

Fuel Capacity

18 Litres / 4.8 US gal

Standing ¼ Mile

10.9 sec / 204.9 km/h / 127.3 mph

Top Speed

266 km/h / 165 mph
.



The middleweight class wars are hotter than ever. And with the new, technologically superior, lighter and faster Ninja® ZX-6RR, bragging rights belong to Kawasaki. The limited-production 599cc ZX-6RR is designed to be the next National and World SuperSport champion. The slimmer, GP-style bodywork hides a lightweight, ultra short-stroke engine with forged racing pistons, electronic fuel injection, slipper clutch, close-ratio gearbox and 15,500 rpm redline. While the pressed aluminum frame doubles as the Ram Air intake and carries an adjustable swingarm pivot. Plus for the first time in the 600cc production class, an inverted cartridge fork and radial-mounted front brake callipers. How serious is it? The ZX-6RR even includes a racing bar-type LCD tachometer and a built-in lap timer. So don’t let the competition beat you to the punch. Get aboard the ZX-6RR, and let them see tail. Yours.

The new Kawasaki NINJA® ZX-6RR sportbike marks a dramatic departure from the broad-spectrum appeal of the earlier Ninja sportbikes, giving the bike a much stronger track bias. The limited edition street-legal ZX-6RR boasts aggressive race-worthy features -including engine, chassis, riding position and overall performance upgrades oriented towards serious sport riding, track days or full-on racing. Designed with the expert and professional racer in mind, this new generation motorcycle is destined to dominate Supersport racing around the world.



Features:

• All-new aerodynamic front fairing helps direct air flow into the new centrally located Ram Air intake system.
• Single gauge instrumentation keeps things light. Digital speedometer surrounded by radial tachometer. Shift indicator lamp with two brightness settings can be manually set at 250 rpm increments above 12,000 rpm.
• Radially-mounted 280mm front disc brakes, a first on a production motorcycle, feature a lighter yet stronger 4-piston calliper for incredible stopping power, rigidity and excellent brake feel. Individual brake pads for each piston reduce heat distortion.
• Built-in lap timer works much like a regular stopwatch that can record up to 99 laps. Start/stop is on the right handlebar switch, while the lap button is on the left.
• Ninja ZX-6RR performance features include over-square 67 x 42.5mm bore and stroke for excellent peak power potential.
• Special 3-ring forged pistons weigh less for less reciprocating mass and reduced friction.
• Back-torque limiter or slipper-style clutch helps prevent rear wheel hop during heavy deceleration.
• Adjustable swingarm pivot point mounting bracket allows for minor adjustment to suit track conditions.
• Remote reservoir rear shock fully adjustable for compression and rebound damping, spring preload and ride height.
• The 599cc Ninja ZX-6RR includes a narrow 25° included valve angle. 4-valve 67mm combustion chamber with an ultra-short 42.5mm stroke for higher rev potential. 13.0:1 high compression. Adjustable cam timing with slotted sprockets.
• Huge 25mm hollow front axle with twin pinch bolts for light weight and added rigidity.
• Lighter, more compact yet exceptionally strong and rigid all-aluminum twin-sparperimeter frame with cylinder head mounts.
• Electronic fuel injection with 38mm throttle bodies reduces emissions and improves throttle response.
• All-new, lighter, centrally located Ram Air induction system increases air intake efficiency at all bike angles.
• High-speed ECU digital ignition processor and individual coils for each spark plug.
• New shorter throw shift lever for the 6-speed transmission that features closer gear ratios from third to sixth to help maximize performance potential.
• 41mm fully adjustable inverted cartridge fork features stepless compression and rebound adjustment plus threaded spring preload.
• Aerodynamic fairing is inspired by our GP program.
