Husqvarna Svartpilen 125

  .

Make Model

Husqvarna Svartpilen 125

Year

2021

Engine

Four stroke, single cylinder, DOHC, 4 valve

Capacity

124 cc / 7.6 cu-in
Bore x Stroke 58 x 47.2 mm
Cooling System Liquid cooled
Compression Ratio 14.5:1
Lubrication Wet sump

Induction

Bosch electronic fuel injection
Emission EURO5

Ignition

Contactless, controlled, fully electronic ignition system with digital ignition timing adjustment

EMS

Bosch EMS
Starting Electric

Max Power

11.3 kW / 15 hp @ 10500 rpm

Max Torque

12 Nm / 8.85 ft-lb @ 8000 rpm
Clutch Wet multi-disc, mechanically actuated

Transmission

6 Speed
Final Drive X-ring chain
Frame Powdercoated steel trellis
Handlebars Tapered aluminum, 26-22mm

Front Suspension

43mm WP Apex inverted non-adjustable open-cartridge fork

Front Wheel Travel 145 mm / 5.6 in

Rear Suspension

Linkage-free, spring-preload adjustable WP Apex shock w/ progressive damping

Rear Wheel Travel 145 mm / 5.6 in

Front Brakes

Single 320mm disc, 4 piston floating calliper

Rear Brakes

Single 230mm disc 1 piston floating calliper
ABS Bosch 10.1 MB two-channel
Wheels Wire-spoked

Front Tyre

110/70 - 17 Pirelli Scorpion Rally STR

Rear Tyre

150/60 - 17 Pirelli Scorpion Rally STR
Steering Head Angle 65 °
Rake 25°
Triple Clamp Offset 32 mm / 1.8 in
Trail 95 mm / 3.7 in
Wheelbase 1357 ± 15.5 mm / 53.4 in
Seat Height 835 mm / 32.9 in
Ground Clearance 145 mm / 5.6 in

Wet Weight

152.8 kg / 337 lbs

Fuel Capacity

9.5 Litres / 2.5 US gal
  .

From a press release by Husqvarna:

HUSQVARNA MOTORCYCLES EXPANDS ITS STREET LINE-UP WITH THE ALL-NEW SVARTPILEN 125
URBAN EXPLORER DELIVERS INDEPENDENCE AND EXCEPTIONAL RIDING EXPERIENCES TO THE YOUTH OF TODAY

Opening up the world of urban exploration to a new generation of youngsters, Husqvarna Motorcycles is pleased to announce the availability of the all-new Svartpilen 125. Expanding the Svartpilen line-up to give younger riders the opportunity to learn and travel with certainty, the single-cylinder machine matches intelligent design with high-end componentry, agile handling and a rugged aesthetic.

With confidence inspiring ergonomics, unique style and assertive performance, the Svartpilen 125 delivers a dynamic riding experience while sharing many of the same high-quality components as found on the larger sized Svartpilen machines. Whether it is riding through inner-city traffic or exploring the open road, the combination of a controllable 125 cc EURO 5 compliant engine with nimble handling and low fuel consumption makes the Svartpilen 125 the perfect choice.

Further boosting the urban credentials, the Svartpilen 125 is fitted with dependable hydraulic ByBre brakes and Bosch ABS technology for superior braking performance and control in all conditions. Ensuring exact rider feedback when navigating busy urban environments, WP APEX 43 mm open cartridge forks and a WP APEX rear shock deliver nimble handling to keep riders comfortable and safe.

The rugged, stripped back appearance of the Svartpilen 125 creates a timeless and authentic look, showcasing the motorcycle’s quality craftmanship and reflecting its dynamic riding experience. A black powder-coated steel frame, striking bronze coloured engine covers and anodised componentry highlight the unique and stylish design.

Technical highlights Svartpilen 125:
- Excellent power-to-weight ratio
- EURO 5 homologated
- A1 licence compliant
- High-quality components and technology
- 17” front and rear spoked wheels fitted with Pirelli tyres
- Premium build quality
- 125 cc single cylinder engine delivers controllable power
- Lightweight - 146 kg without fuel
- CNC machined footrests
- Nimble handling
- LED headlight and taillight
- Low fuel consumption

Accompanying Husqvarna Motorcycles’ range of street motorcycles, the Functional Street Apparel Collection features high-quality products, all designed and made to the highest standards to deliver style and unrestricted movement. To further protect and enhance the Svartpilen 125, an extensive line-up of high-quality Technical Accessories ensures increased durability, personalisation and functionality.
