Husqvarna Svartpilen 801


Make Model

Husqvarna Svartpilen 801




Four stroke, parallel twin cylinder, DOHC, 4 valves per cylinder


799 cc / 48.7 cu in
Bore x Stroke 88 x 65.7 mm
Compression Ratio 12.5:1
Cooling System Liquid / oil heat exchanger
Lubrication Forced oil lubrication with 2 oil pumps
Exhaust Stainless steel primary and secondary silencer
Engine Management Keihin EMS with Ride By Wire


DKK Dellorto (Throttle body 46mm)


Bosch EMS with RBW



Max Power

105 hp / 77 kW @ 9250 rpm

Max Torque

87 Nm / 64.2 lb-ft @ 8000 rpm
Clutch PASC™ slipper clutch, mechanically operated


6 Speed
Final Drive Chain X-Ring
Frame Chromium-Molybdenum-Steel frame using the engine as stressed element, powder coated
Handlebar Forged aluminium triple clamps

Front Suspension

43 mm WP APEX USD forks, Rebound and preload adjustable

Front Wheel Travel

140 mm / 5.5 in

Rear Suspension

WP APEX -Monoshock

Rear Wheel Travel

150 mm / 5.9 in

Front Brakes

Single 300 mm disc, 2 x radially mounted 4 piston Brembo caliper

Rear Brakes

Single 240 mm disc, Brembo 2 piston, floating caliper
ABS Bosch 9.3 MP (incl. Cornering-ABS and Supermoto mode, disengageable)
Wheels Cast aluminium
Front Wheel 3.50 x 17 in
Rear Wheel 5.50 x 17 in

Front Tyre

120/70-R17 Pirelli MT 60 RS

Rear Tyre

180/55-R17 Pirelli MT 60 RS
Rake 24.5°
Trail 97.9 mm / 3.85 in
Steering Head Angle 65.5°
Wheelbase 1388 mm / 54.6 in
Seat Height 820 mm / 32.2 in
Ground Clearance 174 mm / 6.8 in
Dry Weight 181 kg / 399 lbs

Wet Weight

190 kg / 421 lbs

Fuel Capacity

14 Litres / 3.7 US gal

From Hasqvarna press release:

The 2024 Svartpilen 801 is the latest expansion of our naked motorcycle line-up. It combines exceptional versatility, performance, and style for the streets. Its minimalist, scrambler-inspired design features a new compact and powerful parallel-twin engine, perfectly balanced tubular frame, and refined ergonomics for an engaging, intuitive ride. Complete with adjustable WP suspension, state-of-the art electronic aids, and finished with sharp lines and dark colors, the Svartpilen 801 allows each rider to set their own tone for urban riding.

Combining performance, agility, and contemporary scrambler-inspired design, the Svartpilen 801 is the latest and largest displacement naked machine in the brand’s line-up. Engineered to elevate the road riding experience and escape the ordinary, this exceptional motorcycle sets a new standard of excellence for middleweight street models.

Weighing just 181 kg, the Svartpilen 801 is built around a strong and light chromium-molybdenum tubular steel frame for a precise balance of flex and rigidity. At its heart is a powerful 799 cc, parallel-twin, DOHC engine. Tipping the scales at 52 kg dry, the engine offers a peak power output of 105 hp with its reliability and efficiency guaranteed by innovative technologies that extend service intervals to 15,000 km and ensure an extremely low fuel consumption.

The pairing of its lightweight engine and frame gives the Svartpilen 801 a perfectly balanced power-to-weight ratio, resulting in a consistently agile and exciting ride. A Power Assist Slipper Clutch (PASC) system maximises traction under hard acceleration and prevents instability under hard braking, with an Easy Shift providing seamless gear changes. Adjustable WP APEX suspension offers 140 mm of fork travel and 150 mm of shock travel for assured comfort and handling both in and out of town. Pirelli MT60 RS tyres, which are fitted to 17” wheels, provide a high level of grip and feedback.

The minimalist look of the Svartpilen 801 is achieved by its premium details such as the LED lights, and aluminium handlebars coming together to create a unique and eye-catching street machine. Slimline ergonomic bodywork finished in dark tones wraps neatly around the engine and frame with a two-piece seat offering a high level of comfort and unrestricted movement. State-of-the-art electronic aids improve the rideability of the Svartpilen 801 with an optional Dynamic Pack taking the street riding experience to an even higher level. In addition to adjustable Motorcycle Traction Control (MTC) and ABS, Street, Rain, and Sport ride modes are pre-set options as standard. The Dynamic Pack introduces Motor Slip Regulation (MSR) for controlled deceleration with the Anti-Wheelie mode limiting the maximum wheelie angle for extra safety. A best-in-class technology package provides ease of use and maximum performance for every rider. The J.Juan brake system delivers exceptional stopping power thanks to the corner-sensitive Bosch ABS system. For advanced riders, a Supermoto ABS mode can be engaged by those looking for a heightened level of braking feel and a closer connection with the road. Versatility and safety are enhanced by premium electronic features, including a 5” TFT dashboard and Connectivity Unit as standard. Pairing the unit with the Ride Husqvarna Motorcycles app allows for clear Turn-by-Turn navigation to be activated, as well as the ability to control telephone calls and music selection. A Hazard Warning system is also integrated into the handlebar controls while anti-theft protection is provided via the immobiliser.

Technical highlights:
- Chromium-molybdenum steel frame with engine as stressed member
- 799 cc parallel-twin engine with 105 hp peak power and 87 Nm of torque
- Adjustable WP APEX suspension provides exceptional comfort and performance on rugged streets
- Four selectable ride modes (Street, Rain, Sport, plus an optional Dynamic Mode)
- Optional Dynamic Pack introduces ten levels of slip adjustment and five levels of Anti Wheelie
- Motor Slip Regulation, Anti-Wheelie, and Cruise Control available with optional Dynamic Pack
- Standard Cornering Motorcycle Traction Control
- Cutting edge, cornering-sensitive ABS
- Ride-by-wire throttle with adjustable throttle response
- Standard Easy Shift function (up and down Quickshifter)
- PASC Slipper clutch
- Standard Connectivity Unit provides TbT+ navigation, telephone calls, and music selection from the rider’s smartphone
- Hazard Warning system with integrated handlebar switch
