 Ducati Panigale V4 SP2

.

Make Model

Ducati Panigale V4 SP2

Year

2022

Engine

Four stroke, Desmosedici Stradale 90° V4, rearward-rotating crankshaft, 4 Desmodromically actuated valves per cylinder

Capacity

1103 cc / 67.3 cu-in

Bore x Stroke

81 x 53.5 mm

Compression Ratio

14.0:1

Cooling System

Liquid cooled

Exhaust

4-2-1-2 system, with 2 catalytic converters and 4 lambda probes

Induction

Electronic fuel injection system. Twin injectors per cylinder. Full ride-by-wire elliptical throttle bodies. Variable length intake system

Starting

Electric

Max Power

210 hp    / 154.4 kW @ 12500 rpm US spec
215.5 hp / 158.5 kW @ 13000 rpm Euro 5 spec
228 hp    / 167.7 kW Akrapovič

Max Torque

122.8 Nm / 90.6 lb-ft. @ 11000 rpm US spec
123.6 Nm / 91.2 lb-ft. @ 9500 rpm Euro 5 spec
131 Nm    / 96.6 lb-ft Akrapovič

Clutch

Hydraulically controlled slipper dry clutch. Self bleeding master cylinder

Transmission

6 speed with Ducati Quick Shift (DQS) up/down EVO 2

Final Drive

Chain 525; Front sprocket 16; Rear sprocket 41

Gear Ratios

1st 36/15 2nd 34/17 3rd 33/19 4th 32/21 5th 30/22 6th 27/22
Primary Drive Straight cut gears; Ratio 1.80:1

Frame

Aluminum alloy "Front Frame" with optimized stiffnesses

Front Suspension

Öhlins NPX25/30 pressurized 43 mm fully adjustable fork with TiN treatment. Electronic compression and rebound damping adjustment with Öhlins Smart EC 2.0 event-based mode

Front Wheel Travel

125 mm / 4.9 in

Rear Suspension

Fully adjustable Öhlins TTX36 unit. Electronic compression and rebound damping adjustment with Öhlins Smart EC 2.0 event-based mode. Aluminum single-sided swingarm

Rear Wheel Travel

130 mm / 5.1 in

Front Brakes

2 x 330 mm semi-floating discs, radially mounted Brembo Monobloc Stylema® R 4-piston calipers. Self bleeding Brembo MCS 19.21 master cylinder

Rear Brakes

245 mm disc, 2-piston caliper

ABS System

Bosch Cornering ABS EVO
Wheels 5-split spoke carbon fiber

Front Wheel

3.50 x 17

Rear Wheel

6.00 x 17

Front Tyre

120/70 ZR17 Pirelli Diablo Supercorsa SP

Rear Tyre

200/60 ZR17 Pirelli Diablo Supercorsa SP

Rake

24.5°

Trail

100 mm / 3.9 in

Wheelbase

1469 mm / 57.8 in

Seat Height

850 mm / 33.5 in

Dry Weight

173 kg / 381 lbs
168 kg / 370.3 lbs - Akrapovič

Wet Weight

194.5 kg / 428.7 lbs

Fuel Capacity

17 Litres / 4.49 US gal

Instrumentation

Last generation digital unit with 5″ TFT color display
Standard Equipment ucati Power Launch (DPL), Ducati Quick Shift (DQS) up/down EVO 2, Full LED lighting with Daytime Running Light (DRL) Ducati Electronic Suspension (DES) EVO with Öhlins suspension and steering damper, Quick adjustment buttons, Lithium-ion battery, Auto-off indicators, Racing style handle grips, Chain guard, Carbon fiber wheels, Carbon fiber front mudguard, Wings in carbon fiber, Adjustable rider footpegs in aluminum with heel guard in carbon fiber, Billet aluminum steering stem with bike number, Machined brake and clutch levers
Safety Equipment Riding Modes, Power Modes, Cornering ABS EVO, Ducati Traction Control (DTC) EVO 3, Ducati Wheelie Control (DWC) EVO, Ducati Slide Control (DSC), Engine Brake Control (EBC) EVO, Auto tire calibration
Additional Equipment Machined mirror block-off plates, License plate mount removal plug, Carbon fiber open clutch cover,Ducati Data Analyzer+ (DDA+) with GPS module
.

From a press release issued by Ducati:

Ducati presents the Panigale V4 SP2: "The Ultimate Racetrack Machine"

- The Panigale V4 SP2 is the top-of-the-range model for Ducati super sports bikes: a special, exciting version for track riding, even more intuitive and less strenuous also for non-professional riders

- Carbon fibre rims, Brembo Stylema R® brake calipers, MCS radial master cylinder, dry clutch, 520 chain, billet footpegs and a specific kit for track use: the "SP" technical specifications push to the maximum the racing characteristics of the Panigale V4 and accompany all the improvements made on the 2022 version

- Produced in a numbered series, the Panigale V4 SP2 is characterized by the "Winter Test" livery and a series of carbon fibre details

In the ninth and final episode of the Ducati World Première 2022 web series, Ducati unveiled the new Panigale V4 SP2 to enthusiasts: a special motorcycle in a numbered series, designed to fully experience the passion for riding on the track, further raising the performance of the Panigale V4.

The Ducati Panigale family is the maximum expression of the continuous exchange of information and technology from the world of racing to production bikes and with each new version it continues its evolution year after year, just as it happens with the Ducati Corse prototypes. The "SP2" is the model with which Ducati brings to the peak the sportiness of the Panigale V4 , the 2022 version of which has taken the most significant evolutionary step since its inception, improving in every aspect: aerodynamics, ergonomics, engine, chassis and electronics.

The Panigale V4 SP2 stands out for its equipment with the typical technical specifications of the abbreviation "SP" (Sport Production) which are combined with all the improvements made by Ducati engineers on the Panigale V4 2022 to create the most high-performing Panigale ever.

The “SP2” version has an even more powerful braking system, lightweight carbon rims, final drive and dry clutch inherited from the WorldSBK bikes, racing footpegs and a series of carbon components. The bike is also delivered with a kit for track use, which includes billet aluminium caps for the removal of rear-view mirrors, kit for removing the license plate holder and open carbon clutch cover.

The result is “The Ultimate Racetrack Machine”: a special model, ideal for the non-professional rider who wishes to experience track days challenging his own records.

The Panigale V4 SP2 is characterized by the "Winter Test" livery, in which the matt black of the fairings is combined with the matt carbon finish of the rims and wings, contrasting with the bright red accents and the brilliance of the exposed brushed aluminium tank. The wings with double profile design are embellished with the Italian flag which also appears on the official Panigale V4 R SBK. The lower part of the fairing is distinguished by the presence of the Ducati Corse logo in the area of ​​the new hot air extractors and by a red detail bearing the name of the bike, also present on the black saddle in double material. The steering head is machined from solid and shows the progressive number of the motorcycle, making each model unique.

The heart of the Panigale V4 SP2 is the 1,103 cc Desmosedici Stradale derived from MotoGP: a V4 with counter-rotating crankshaft equipped with a lot of torque from low revs and capable of expressing the racing soul of the bike on the track. For 2022, the Desmosedici Stradale has improved with the introduction of dedicated technical elements, which have made it possible to increase power and improve throttle response.

Thanks to these interventions and a new dedicated mapping, the Euro 5 version engine delivers 215.5 hp at 13,000 rpm, with a power increase of 1.5 hp over the Panigale V4 2021, which rises to 2.5 hp beyond the maximum power peak at 14,500 rpm.

To capitalize on the full potential of this engine, dedicated gear-by-gear torque curves and four different Power Modes (Full, High, Medium, Low) have been developed by Ducati. The Full and Low configurations are newly developed, while the High and Medium configurations use a new strategy.

When used on the track, the performance of the Desmosedici Stradale can be further improved with the new full titanium Ducati Performance racing exhaust, developed in collaboration with Akrapovič and available as an accessory.
This exhaust is equipped with high silencers alongside the tail and has been redesigned to increase performance and limit noise, offering everyone the opportunity to run with a full racing exhaust even in circuits with the most stringent noise limits. With this exhaust the Panigale V4 SP2 is lightened by 5 kg thus taking the dry weight of the motorcycle to only 168 kg. The Akrapovič exhaust also guarantees an increase in power of 12.5 hp, bringing the maximum value to 228 hp, while the maximum torque value rises to 131 Nm.

The connection to the bikes that race in the Superbike World Championship is even more evident in the “SP2” version of the Panigale V4. In fact, to the more “track-oriented” gearbox already presented on the Panigale V4 2022, this bike adds the lightened final drive with 520 chain and the STM-EVO SBK dry clutch. This clutch guarantees a more effective anti-hopping function in extreme use of the bike on the track and greater fluidity in all phases of "off throttle" compared to the oil bath clutch of the Panigale V4 S. The STM-EVO SBK clutch also offers the possibility to customize the “mechanical” engine brake level by choosing a different secondary spring from those available in the Ducati Performance accessories catalogue.

The chassis of the Panigale V4 SP2 includes an aluminium front frame that uses the Desmosedici Stradale as a stressed element. The aluminium swingarm and the seat post in shell-cast aluminium are directly connected to the engine. The pivot of the swingarm is positioned in such a way as to increase the anti-squat effect, which is the reduction of the sinking of the rear when exiting corners and when reopening the throttle, thus stabilizing the bike in acceleration.

The suspension system features an electronically controlled 125 mm travel Öhlins NPX25/30 pressurized fork at the front that uses a pressurized cartridge damping system derived from that of racing forks. This fork, in combination with the Öhlins TTX36 shock absorber and with the electronic steering damper, also Öhlins, forms the second generation of the Smart EC 2.0 system characterized by OBTI (Objective Based Tuning Interface) logic which, working "by objectives" and not by clicks, allows the rider a much more intuitive management than traditional systems.

To further enhance the performance on the track and the dynamic qualities of the Panigale V4, the "SP2" version is equipped with 5-split spoke carbon wheels , 1.4 kg lighter than the aluminium forged ones of the Panigale V4 S. The carbon rims guarantee a significant reduction in inertia (-26% at the front, -46% at the rear) to the benefit of agility, lightness in direction changes and greater ease in closing the curves.

The Panigale V4 SP2 is also equipped with exclusive Brembo Stylema R® front brake calipers, which guarantee high braking power combined with exceptional consistency of performance even during a lengthy timed session without changes to the travel of the brake lever. The calipers are operated by a Brembo MCS (Multiple Click System) radial pump that allows you to adjust the wheelbase quickly and easily on three configurations to customize the braking feeling. The front brake lever is equipped with a “remote adjuster” device, which allows you to adjust its position by acting on a knob on the left grip, as is the case on racing bikes. Finally, on the "SP2" version the brake and clutch levers are milled at the ends to reduce air resistance.

Another essential element that characterizes the Panigale V4 SP2 is the equipment with Rizoma footpegs in anodized aluminium with carbon fibre heel guards. The footpegs are fully adjustable and maximize ground clearance for more effective use on the track. These racing footpegs offer great grip for the boots, essential for riding at the limit on the circuit, further contributing to a completely redesigned ergonomics in 2022 with the new tank and saddle shapes, studied to improve control and make the most of the performance of the Panigale V4 both on the flying lap and during a prolonged session.

The Panigale V4 SP2 has an electronic package that includes controls that manage all the riding phases, whose operating parameters are linked by default to the 4 Riding Modes (Race A, Race B, Sport, Street).

All the electronic parameters of the bike can be clearly visualized thanks to the dashboard and to the "Track Evo" display mode , derived from the one used in MotoGP. In this screen, the tachometer moves on a horizontal scale positioned in the highest part of the instrument, or the most visible, and the indication of the gear engaged is in the centre of the screen. In the right area of ​​the display there are four different coloured sectors, each dedicated to an electronic control (DTC, DWC, DSC, EBC). These sectors light up individually when the electronics are working on a certain parameter, remaining on for the time necessary for the rider to identify which indicator is activated. This signalling mode facilitates the rider’s task in understanding the control that has worked to allow him to intervene in a more precise and timely way on the choice of optimal level and to achieve better performance more quickly. The left sector completes the information with the chronometer, number of laps completed and speed.

On the "SP2" version, the GPS module is standard, thus allowing the activation of the automatic Lap Time function, which instantly provides the indication of two split times of the track on which you are lapping. Furthermore, by loading the Slick Ducati Performance Software (available as an accessory), Ducati Traction Control curves expressly developed for slick and rain tyres are available and the possibility of memorizing the coordinates of five different tracks is activated, as well as five additional fully customizable Riding Modes. Finally, thanks to the Ducati Data Analyzer, standard on the SP2, it is possible to conduct an in-depth analysis of all performance data.

The new Panigale V4 SP2 is available in single-seater configuration in "Winter Test" livery.
