Benelli 500LS

Make Model	Benelli 500LS
Year	1977
Engine	Four stroke, transverse four cylinders , 2 valves per cylinder
Capacity	498 cc / 30.4 cu in
Bore x Stroke	56 x 50.6 mm
Compression Ratio	10.2:1
Oil Capacity	2.5 L / 2.6 US qts
Induction	4 x 22mm Dell'Orto carburetors
Starting	Electric and kick start
Max Power	36.5 kW / 49 hp @ 8500 rpm
Max Torque	34 Nm / 3.47 kgf-m / 25.1 lbs-ft @ 9300 rpm
Transmission	5 Speed
Final drive	Chain
Front Suspension	Telescopic forks
Rear Suspension	Pivoted rear fork 5-way spring preload
Front Brakes	2 x 260mm discs
Rear Brakes	200 mm drum
Front Tyre	3.00-18
Rear Tyre	3.50-18
Dimensions	Length: 2100 mm / 82.7 in Width: 800 mm / 31.5 in Height: 1000 mm / 39.4 in
Dry Weight	198 kg / 437 lbs
Wet Weight	230 kg / 507 lbs
Fuel Capacity	19 Litres / 5.02 US gal
Fuel Consumption	6.7 L/100 km / 14.9 km/l / 35.1 US mpg
Top Speed	180 km/h / 111 mph
