Honda XR 250R

.

Make Model

Honda XR 250RD

Year

1983

Engine

Four stroke, single cylinder SOHC, 4 valve

Capacity

249 cc / 15.2 cu-in
Bore x Stroke 74 x 57.8 mm
Cooling System Air cooled
Compression Ratio 10.0:1

Induction

Piston valve

Ignition

Capasitor-Discharge
Spark Plug D&EA, Plug gap .028
Starting Kick

Max Power

30 hp / 21.9 kW @ 9000 rpm

Max Torque

24.5 Nm / 18 ft-lb @ 7500 rpm
Clutch Wet, four friction discs

Transmission

6 Speed
Final Drive Chain,  #520 x 106

Front Suspension

Leading axel air spring 38mm forks
Front Wheel Travel 240 mm / 9.4 in

Rear Suspension

Pro-link Kayaba damper adjustment for spring preload and rebound damping
Rear Wheel Travel 247 mm / 9.7 in

Front Brakes

Drum

Rear Brakes

Drum

Front Tyre

3.00-21

Rear Tyre

5.10-17

Dimensions

Length 2160 mm / 85 in
Width 850 mm / 33.4 in
Height 1235 mm / 48.6 in
Wheelbase 1420 mm /  55.9 in
Seat Height 945 mm  /  37.2 in
Ground Clearance 320 mm /  12.5 in

Dry Weight

119 kg / 262 lbs

Fuel Capacity

9.8 Litres / 2.6 US gal

Road Test

Cycle Magazine
.
