Honda RVF 400R

.

Make Model

Honda RVF 400R (NC35)

Year

1995

Engine

Four stroke 90°V-four cylinder, DOHC, 4 valves per cylinder.

Capacity

399 cc / 24.3 cu-in
Bore x Stroke 55 x 42 mm
Valve Clearance Intake - 0.15 mm / Exhaust 0.24
Cooling System Liquid cooled
Compression Ratio 11.3:1
Lubrication Wet sump
Engine Oil SAE 10W-40
Oil Capacity 2.4 Litres

Induction

 4 x 34mm Keihin Carburetors

Ignition

Digitalized full transistor ignition
Spark Plug NGK ER9EH
Starting Electric

Max Power

61 hp / 45 kW @ 12500 rpm

Max Torque

35 Nm / 3.7 kgf-m @ 10000 rpm
Clutch Wet, cable operated

Transmission

6 Speed
Final Drive Chain
Frame Twin-spar aluminum

Front Suspension

41mm inverted forks: preload and rebound damping
Fork oil Per Rod
390 ml / SAE 7,5W

Rear Suspension

Rising-rate monoshock. pre-load and rebound damping

Front Brakes

2 x 269mm 4 piston calipers

Rear Brakes

Single disc 2 piston caliper

Front Tyre

120/60 R17

Rear Tyre

150/60 R17
Rake 24°
Trail 96 mm / 3.7 in
Dimensions Height  1075 mm / 42.3 in
Length 1985 mm / 78.1 in
Wheelbase 1345 mm / 53.0 in
Seat Height 780 mm / 30.7 in

Dry Weight

165 kg / 363.8 lbs

Fuel Capacity

16 Litres / 3.9 gal

Consumption Average

42 mpg

Standing ¼ Mile

12.6 sec / 109 mph

Top Speed

219 km/h / 136.2 mph
.

The V-Four 400cc. It's a hot, hot bike! It looks just like RVF750 (RC45) except the headlights are smaller and shaped more like the Factory RVF Suzuka 8-hour Endurance bike. Fully adjustable upside down forks are featured even though the CBR400RR still sports conventional forks. The "claimed" max horse power and torque are reduced due to a notice from department of traffic in Japan*.

Finally switched wheels from the RC30 like 17" front 18" rear to the now standard 17" at both ends. Like the VFR400R(NC30), the RVF400(NC35) is known for great handling and turning quicker than other 400s. It sports the latest Nissin 4 piston calipers (black colored). Graphics are just like the RC45 - mostly red and white with some purple and black on the fairing sides. Black number plates and wheels round out the look.

The third incarnation of the VFR400 (the NC30) is an RC30 lookalike, and has turned out to be arguably the best 400cc sports bike. It had the best 400cc engine and by far the best looks, and has been the biggest seller. It was 'upgraded' to an RVF (NC35) in 1994 , echoing the lines of the RC45. In truth, it had a styling makeover, upside-down forks and a ram-air system but was virtually the same machine with virtually identical power and performance figures. The little VFR has proved itself to be popular by virtue of its brilliance. The review says it all:

You don't have to ride the NC30 to know that it is right. Everything about it just looks right. The scaled-down version of the RC30 is perfect in it proportions and in its detail. The reduction in size makes it neater still.

The engine gives the impression of that of a larger machine. Peak torque is at 12,000rpm, but it doesn't drop off, giving a long, flexible spread of peak power. It will hold any top gear cruise speed up to 100mph, will pull wide open in top from 2,000rpm and runs without a hiccup to 15,000rpm.



Asked whether the quality of engineering is worth £6,000, the answer would be yes. The build quality is nearly as good as the RC30.

The VFR400 was featured in Bike magazine's secondhand buyer's guide, in the October 2001 issue. These are some of the things they said:


It doesn't matter who you are or what sort of bike you ride you can't fail to be impressed by the NC30. It is quite simply the best sportsbike under 600cc, with the possible exception of the Aprilia RS250. Beautifully engineered, beautifully built and beautifully finished, it exudes such quality that you wonder how they built it at the price.

Reliable? Absolutely, assuming that it's been properly maintained. The charging system is a bit suspect, but that's it. Check the trueness of the wheels - they distort easily.
[Note: Regulator/rectifiers can fail, just like the bigger VFRs, that's all].

Competition: There isn't any, really. The NC35 is even more gorgeous (and expensive), an utter work of art. The CBR400 is a contender. It's another wonderful miniature road burner with superlative handling and a tough engine, but it just doesn't have the quality feel that you get with the NC30.

Source simonevans.co.uk
