Honda GL 1200 Gold Wing

.

Make Model

Honda GL 1200 Gold Wing Aspencade

Year

1985

Engine

Four stroke, Opposed boxer four cylinders, SOHC, 2 valve per cylinder

Capacity

1182 cc / 72.1 cub in.
Bore x Stroke 75.5 x 66 mm
Compression Ratio 9.0:1

Cooling System

Liquid cooled

Induction

4x 32 mm Keihin carburetors

Ignition

Electronic

Starting

Electric

Max Power

70.1 kW / 94 hp @ 7000 rpm

Max Power Rear Tyre

62.6 kW / 83.9 hp @ 7250 rpm

Max Torque

104.9 Nm / 10.7 kgf-m / 77.4 lb-ft @ 5500 rpm

Transmission

5 Speed

Final Drive

Shaft

Front Suspension

Telescopic with air assisted spring and 4-position anti-dive.

Front Wheel Travel

140 mm / 5.5 in.

Rear Suspension

Twin adjustable shocks

Rear Wheel Travel

100 mm / 3.9 in.

Front Brakes

2 x 276 mm discs, 2 piston calipers

Rear Brakes

Single 296 mm disc, 2 piston caliper

Front Tyre

130/90 H16

Rear Tyre

150/90 H15

Rake

30°

Trail

120 mm / 4.6 in.
Length 2355 mm / 92.7 in.
Wheelbase 1610 mm / 63.4 in.
Seat Height 780 mm / 30.7 in.

Dry-Weight

330 kg / 728 lbs

Fuel Capacity

22 Litres / 5.8 US gal

Consumption Average

5.7 L/100 km / 17.4 km/l / 41 US mpg

Standing ¼ Mile

13.3 sec 145 km/h / 90 mph

Top Speed

243 km/h / 151 mp/h
