Honda CX 500TC Turbo

.

Make Model

Honda CX 500TC Turbo

Year

1982

Engine

Four stroke, Turbo charged, longitudinal 800 V-twin cylinder, camshaft nestles at the base of the V between the cylinders. ,OHV, 4 valves per cylinder operated by pushrods

Capacity

498 cc / 30.3 cu-in
Bore x Stroke 78 x 53 mm
Compression Ratio 7.2:1

Induction

Electronic  fuel injection

Ignition

CDI
Starting Electric

Max Power

82 hp / 59.9 kW @ 8000 rpm  ( rear tyre 76 hp @ 8000 rpm )

Max Torque

79 Nm / 58.2 lb-ft @ 5000 rpm
Clutch Wet, multi-plate, 5-speed

Transmission

5 Speed
Final Drive Shaft

Front Suspension

37mm Showa, adjustments for TRAC anti-dive and air pressure
Front Wheel Travel 130 mm / 5.1 in

Rear Suspension

Honda Pro-Link, one Showa damper, adjustment for air pressure and rebound damping
Rear Wheel Travel 104 mm / 4.1 in

Front Brakes

2x 280mm discs

Rear Brakes

Single 300mm disc

Front Tyre

100/90 V18

Rear Tyre

120/90 V17

Dry Weight

220 kg / 485 lbs
wet-Weight 263 kg / 579.8 lbs

Fuel Capacity

20 Litres / 5.2 US gal

Consumption Average

47 mpg

Braking 60 - 0 / 100 - 0

-  / 13.5 m

Standing ¼ Mile

12.3 sec  / 106 mph

Top Speed

206 km/h / 128 mph

Road Test

Cycle World 1981

Cycle 1982

CBX vs CX Turbo

.

The CX500 Turbo with which Honda stunned the motorcycle world in 1982 was one of the least likely bikes ever to be put into production. The turbocharged V-twin was large, heavy, complex and expensive. From the moment it was unveiled, many observers regarded the Turbo as more of a corporate statement than a serious superbike.

Honda's ostentatious V-twin was the first of the string of turbocharged machines that would see all of the big four Japanese manufacturers try their luck with forced induction. The Honda was the most curious in its choice of powcrplant. Turbochargers. which use exhaust gas to compress the intake charge, arc best suited to large engines that operate at a steady load: the opposite of a motorcycle's situation. In addition, multi-cylinder motors help by smoothing the exhaust flow.



Despite this. Honda selected their middleweight CX500. an 80-degree transverse V-twin with pushrod valve operation. The CX's small cylinders required the world's tiniest turbocharger, which was built by IHI to Honda's specification. Its rotors measured less than two inches (51mm) in diameter and were designed to spin at 200,0001pm.





Strengthened engine

The CX's crankcases were strong enough to be retained, but much of liquid-cooled engine was uprated. A stronger crankshaft, clutch and conrods, plus Honda's first production-specification forged pistons, all helped to keep it together when the turbo increased peak power from the standard CX500's 50bhp to the Turbo's 82bhp at 8000rpm.

Honda's work by no means ended with the power plant. The CX was a rolling showcase for other technical achievements, including its digital ignition and fuel-injection system. Pro-Link rear suspension. TRAC anti-dive, twin-piston brake calipers and redesigned Comstar wheels. In addition the fairing, with its lipped screen, enormous headlamp and integral indicators, was undeniably stylish. It held a sophisticated instrument console that contained a clock and fuel gauge, as well as the turbo boost gauge.





The fairing worked well. too. allowing highspeed cruising in comfort. The CX also handled very well considering its fuelled-up weight of over 5501b (250kg). But for such a big. expensive bike the Turbo was only moderately fast. It was good for 125mph (201km/h) but its acceleration was marred by all that weight. And the engine also suffered from turbo-lag. the intrusive delay between throttle opening and engine response which made precise throttle control difficult.

For long-distance riding at speed the Turbo was impressive even so. but it was not so outstanding that its weight, complexity and expense were overcome. A year later, in 1983. Honda followed it with the CX650 Turbo, which had less lag plus a substantial power increase that gave thrilling acceleration and a top speed of 135mph (217km/h). The bigger model was an even better grand tourer. But it was still not a sales success against simpler, cheaper rivals, and remained in production for only a year.



Blown Four: the ZX750 Turbo

The last, fastest and best of the Japanese turbo-bikes was Kawasaki's ZX750 Turbo of 1984. Like Yamaha's XJ650 Turbo and Suzuki's XN85 (which also had a capacity of 650cc) the ZX was an in-line four. In style and chassis layout it resembled Kawasaki's GPz1100. Peak power was 112bhp, and the Kawasaki had very little turbo lag because its turbine was in front of the engine, so exhaust gas travelled a short distance before reaching it. With fine handling and a top speed of almost 140mph (225km/h), the ZX750 Turbo had comparable performance to the GPz1100. It sold in reasonable numbers before Kawasaki, too, finally abandoned turbo-bike production.
