Honda CR 500R

Make Model	Honda CR 500R
Year	1983
Engine	Two stroke, single cylinder, membrane & power valve
Capacity	491.4 cc / 29.9 cu-in
Bore x Stroke	89.0 x 79.0 mm
Compression Ratio	6.7:1
Cooling System	Air cooled
Exhaust	Expansion chamber
Lubrication	Pre-mix
Induction	Single 38mm Keihin flat-slide carburettor
Ignition	CDI
Starting	Kick
Max Power	59 hp / 44 kW @ 6600 rpm
Max Torque	65.7 Nm / 48.5 lb-ft @ 6600 rpm
Clutch	Wet plate
Transmission	5 Speed
Final Drive	Chain
Primary Reduction	2.520
Final Reduction	3.500
Gear Ratio	1st 1.750 / 2nd 1.388 / 3rd 1.150 / 4th 1.000 / 5th 0.870
Frame	Welded steel tubing
Front Suspension	46mm Showa telescopic fork
Front Wheel Travel	305 mm / 12.0 in
Rear Suspension	Showa Prolink with adjustable compression/rebound dampening
Rear Wheel Travel	315 mm / 12.4 in
Front Brakes	Single 240mm disc hydraulic 2 piston caliper
Rear Brakes	Drum
Front Tyre	3.00-21
Rear Tyre	5.10-18
Rake	27°
Trail	109.2 mm / 4.3 in
Wheelbase	1508.7 mm / 59.4 in
Seat Height	937 mm / 36.8 in
Ground Clearance	320 mm / 12.6 in
Dry Weight	102.1 kg / 225.0 lbs
Wet Weight	108.0 Kg / 238.1 lbs
Fuel Capacity	9 Litres / 2.38 US gal
Overview	Pulpmx.com
