Honda CBR 1000RR Fireblade

.

Make Model

Honda CBR 1000RR Fireblade

Year

2007

Engine

Four stroke, transverse four cylinder, DOHC, 4 valve per cylinder.

Capacity

998 cc / 60.9 cu-in
Bore x Stroke 75 x 56.5 mm
Compression Ratio 12.2:1
Cooling System Liquid cooled
Lubrication Wet sump
Engine Oil Synthetic, 10W/40

Induction

PGM-DSFI fuel injection, 4 x 44mm throttle bodies

Ignition

Computer-controlled digital transistorized with electronic advance
Spark Plug NGK, IMR9C-9HES
Starting Electric

Max Power

126,4 kW /172 hp @  11250 rpm

Max Torque

115 Nm / 11.73 kg-m  @ 10000 rpm

Transmission

6 Speed
Final Drive Chain
Frame Aluminium, twin spar

Front Suspension

43mm inverted HMAS cartridge fork with spring preload, rebound and compression damping adjustability;
Front Wheel Travel 120 mm  / 4.3 in

Rear Suspension

Pro-Link single shock with spring preload, rebound and compression damping adjustability;
Rear Wheel Travel 135 mm / 5.4 in

Front Brakes

2x 320mm discs 4 piston calipers

Rear Brakes

Single 220mm disc 1 piston calliper

Front Tyre

120/70 ZR17

Rear Tyre

190/50 ZR17
Rake (Caster Angle) 23.3°
Trail  102 mm / 4.5 in
Dimensions Length 2025 mm / 79.7 in
Width 720 mm / 26.9 in
Height 1120 mm / 44.0 in
Wheelbase 1407 mm / 55.4 in
Seat Height 828 mm / 32.3 in
Ground Clearance 130 mm / 5.1 in

Dry Weight

176 kg / 388 lbs

Wet Weight

202 kg / 445 lbs

Fuel Capacity

18 Litres / 4.8 gal

Consumption Average

16.5  km/lit

Standing ¼ Mile

10.6 sec

Top Speed

277.7  km/h

Overview

A tweaked engine with new pistons and an altered head boosted power, while lower final drive ratios improved acceleration.
• James Toseland took the 2007 WSB title on the Ten Kate Blade, its first world championship.
• John McGuinness broke the 130mph average TT lap barrier in 2007, with a 130.354mph lap.

.



Features

- Dual Stage Fuel Injection (DSFI) system features two injectors per cylinder.

- Aggressive styling based on the championship-winning RC211V MotoGP machine.



Engine/Drivetrain

- Liquid-cooled DOHC 16-valve 998cc four-stroke inline four-cylinder engine features bore-and-stroke dimensions of 75mm x 56.5mm.

- Sixteen-valve cylinder head features 29mm intake and 24mm exhaust valves with a 12.2:1 compression ratio for efficient combustion and high horsepower.

- Intake valve features double-spring design for optimum performance at high rpm.

- Direct shim-under-bucket valve actuation system ensures high-rpm durability and allows 16,000-mile valve maintenance intervals.

- Lightweight nutless connecting rods.

- Iridium-tip spark plugs improve fuel combustion and performance.

- DSFI system features two injectors per cylinder--one upper and one lower--controlled by an electronic control unit (ECU) that senses rpm and throttle opening. Lower injector enhances rideability while upper injector improves top-end horsepower. At lower rpm only the lower injector is working. At higher rpm, both injectors are activated. The system uses 44mm throttle bodies.

- Denso injectors with lightweight valving for faster reaction time and 12 holes per injector improve atomization of fuel mixture for optimum combustion efficiency and power.

- Auto-enriching system is integrated into programmed fuel injection (PGM-FI) module, eliminating the need for a manual choke.

- Forged aluminum pistons with moly surface treatment for reduced friction.

- Aluminum composite cylinder sleeves are high-pressure-formed from sintered aluminum powder impregnated with ceramic and graphite. The lightweight composite sleeves provide better wear resistance and superior heat dissipation compared to conventional sleeves.

- ECU provides two digital 3-D fuel-injection maps for each cylinder and two digital 3-D ignition maps for cylinder pairs, creating ideal fuel mixture and spark advance settings for superb rideability.

- Ram-air system allows high volume of cool air to the 8.35-liter airbox for linear power delivery and incredible engine performance.

- Stainless steel four-into-two-into-one center-up exhaust with twin outlets and titanium core increases lean angle and reduces wind drag.

- Liquid-cooled aluminum oil cooler is lightweight and efficient.

- Magnesium ACG cover for lighter weight.

- Maintenance-free automatic cam-chain tensioner.

- Starter gears located on the right side to produce narrow engine and increased lean angle.

- Eight-plate clutch is compact and tough, featuring durable friction plate material.

- Cassette-type, close-ratio six-speed transmission is easily accessible for rapid gear ratio changes and maintenance at the race track.

- Durable #530 O-ring-sealed drive chain.

 SUSPENSION

- Lightweight, twin-spar aluminum frame utilizes RC211V technology.

- Aluminum-hybrid rear swingarm is longest in class for superior traction under hard acceleration.

- New aluminum subframe is lightweight and easily removed for ease of maintenance.

- HESD is a rotary-type steering damper that electronically modulates steering damping based on road speed and acceleration. An ECU senses road speed and acceleration and then sends a signal to a solenoid. The solenoid controls an oil-pressure relief valve within the damper unit. At slower speeds the relief valve is open, allowing for a free flow of oil through the damper unit, resulting in reduced damping force and lighter steering effort. At higher speeds the flow of oil is restricted, resulting in increased damping force and additional stability. HESD is the first steering-damping system that makes it possible to increase high-speed performance while maintaining low-speed handling.

- 43mm inverted aluminum-slider Honda Multi-Action System (HMAS) cartridge front fork features spring preload and rebound and compression damping adjustability, and offers precise action and unparalleled rigidity.

- Unit Pro-Link rear suspension system is patterned after the RC211V MotoGP machine. In this system, the upper shock mount is contained within the swingarm rather than the frame. With no top frame mount for the shock, this unique system reduces negative suspension energy from being transmitted into the frame, allowing optimum frame rigidity and improved rideability out of corners. The HMAS shock offers rebound and compression damping and spring preload adjustability.

- Front-brake system features radial-mounted four-piston calipers and 320mm floating discs, and a 220mm rear disc with a single-piston caliper for exceptional stopping power.

- Super-light, aluminum-alloy hollow-spoke wheels feature race-spec 3.5 x 17-inch front and 6.0 x 17-inch rear dimensions.

- Centrally mounted 4.8-gallon fuel tank is positioned low in the frame, increasing mass centralization and allowing a more compact design. This design positions the rider farther forward for optimum handling.

 Additional Features

- High-capacity 350-watt AC generator.

- High-tech instrument display features tachometer, LCD readouts for speedometer, coolant temperature, odometer, two tripmeters and a clock. A low-fuel LED light and shift-indicator light is located in the tachometer.

- Line-beam headlight features three-piece reflector design utilizing two H7 bulbs for optimum light distribution and unique compact design.

- LED taillights for improved appearance.

- Plastic tank shell cover protects tank and airbox.

- One-piece fan assembly increases cooling efficiency.

- Convenient ignition switch/fork lock for added security.

- Folding aerodynamic mirrors.

- Handlebar switches and controls use internationally approved ISO graphic symbols.

- Convenient push-to-cancel turn-signal switch.

- Maintenance-free battery.

- Transferable one-year, unlimited-mileage limited warranty; extended coverage available with a Honda Protection Plan.

- Purchase of a new, previously unregistered Honda unit by an individual retail user in the United States qualifies the owner for a one-year complimentary membership in the Honda Rider's Club of America® (HRCA®). Benefits include roadside assistance, online access to the Honda Common Service Manual, six issues of the bimonthly Honda Red Rider™ magazine, travel discounts, trip routing and MSF reimbursement, plus access to the HRCA Web site (www.hrca.honda.com). For details on the HRCA, dealers should call (310) 783-3958, 8:30 a.m. to 5 p.m. Pacific Time.


Available accessories

- Passenger Seat Cowl (color-matched).

Review

Light Makes Might! Soup Test: 2006 Honda CBR1000RR
seventeen pounds lighter, but the mass centralization gives it viagra-like confidence
by andy fenwick

Tuesday, January 16, 2006
The 2006 CBR1000RR squats and pulls at Buttonwillow Raceway with ex-national champion Andy Fenwick in the Soup-tester hot-seat. Fenwick said the friendly powerband and excellent chassis of the '06 1000RR almost made him misread the bike, 'until you see the world going by you like you've fallen off the planet'.
image by kevin wing

Floating a wheelie half-way down the straightaway at Buttonwillow Raceway is a hell of a lot better gig than my usual day of sweeping the floor and selling $5.00 inner tubes at my shop.

Dean, the Grand Pooh-Bah of Soup, was kind enough to send me on the press launch of the 2006 Honda CBR1000RR. I'd been thinking for weeks about what the new flagship Superbike model from Honda would be like as I have had an opportunity to ride a bunch of different 1000cc sport bikes in my day but not the Honda as yet. I had more questions than answers, as usual, and most of them pertained to the speed and agility of this motorcycle.

Between the fuel tank and dash sits the HESD (Honda Electronic Steering Damper), which is not new for this model but still quite revolutionary. Essentially a electronicly controlled rotary steering damper, it provides less damping at lower speeds and more--when you need it--at faster speeds.
image by kevin wing
Big-bore sport bikes are my forte'. Kurt Hall, Tim Morrisey, Ben Martinez and I won the 1988 WERA National Endurance championship on a very hot-rodded Yamaha FZR1000 for a team called the Human Race Team--run by Dave Zupan.
We raced for the championship against a couple of guys you may have heard of—Jamie James and the late Mike Harth. James won the US Superbike championship in 1989 so you can be assured this was no minor league contest.





While the name is the same, the '06 CBBR1000RR shares little with the previous model. With a fairly broad brush Honda re-designed the top-end of the engine, lightened the bike up by 17 pounds, and revised the chassis and suspension.
image by kevin wing
Since I am sort of the low man on the bike-test list, I figured Dean was trying to bribe me hoping to get his hands on some of my hand-made ice tires for his CRF150. I looked at the thermometer the day I left for the test—it sat at twenty-odd degrees. It was time to get out of Dodge.

Most of you probably don't know how these press launches work, so I'll give you the cliff notes. Basically, journalists fly to wherever the launch is to be. Generally, you stay at a hotel a lot nicer than the one you'd stay in if you were paying for it. The manufacturer has a briefing to give you all the info on all the new bits, and the increased this and the reduced that. There tends to be a fair amount of fancy eating for dinners and such. Most of the time, there is some sort of swag that comes your way—a new watch, fleece pullover, or whatever (we received Honda/Ogio backpacks this time). Hopefully, the tester has such a good time riding the bike, eating the food, and admiring themselves in their new swag in the hotel room mirror that they write a killer review of the bike. As for me, I own a bike shop I can source just about any kind of cool t-shirt or other piece of SWAG, this treatment has little effect on me.



Honda says that the '06 1000RR shares DNA with the RC211V MotoGP racer. With the new, tighter bodywork it is a great looking sport bike, with basically no bad asthetic points at all. Typical.
image by kevin wing
This test was just up the road from Bakersfield, California, at the scrappy, not crappy, (I actually ended up liking the place) Buttonwillow road race facility. For those of you who have never been to Buttonwillow, it's probably one of the best not-so-best places to test a sportbike. It's technical layout and somewhat used track surface really lets you explore not only the handling, but also the suspension of a test bike. We used the full circuit so it reall gave us a nice group of different corners on which to test the bike's handling, etc.

Think the Honda-speak about the CBR1000RR "sharing DNA" with the RC211V is just PR gloss? Think again. Head of the CBR1000RR project is Noriaki Nakata, former manager of the Honda GP/MotoGP team. Here; he stands with Soup-man Fenwick. 'Please, what is WERA Endurance series?'
image by kevin wing
The night we arrived in Bakersfield, Honda's press men went over all of the development that went into the 2006 CBR. Quite surprisingly, 60% of the bike's components have been redesigned on this new model. Targeted areas of improvement were, of course, increased horsepower of approximately 3%, decreased weight resulting in 17 pounds shaved, and sharpened handling. Honda also gave the big CBR1000RR a bit of a face-lift. The bike's more aggressive, sleeker, and curvaceous looks not only show more of the power plant, but also increase the aerodynamic efficiency of the bike, along with complementing its high-speed handling.

A stainless four-into-two-into one exhaust system with twin exits (they're looking at ya' here) highlight the path the spent fuel travel after the CBR's finshed with 'em.
image by kevin wing
Getting more ponies out of the motor meant relying on the classic hot-rodder's handbook. The new engine has updated intake and exhaust porting, a higher compression ratio (from 11.9:1 to 12.2:1), revised cam timing, double springs for the intake valves, a higher redline, and a new exhaust system.



The 2006 model is now 17 pounds lighter than the 2005. Weight savings were brought about by adding magnesium where there was once aluminum, lighter radiators, larger but thinner brake rotors, and generally sprinkling magic Honda fairy dust over all things that looked heavy.

Mass-centralization is key in the Honda's chassis: —the 4.8 gallon fuel tank is positioned low in the frame, which lets the rider sit forward slightly.
image by kevin wing
I, along with seven other journalist types were escorted around the track by former world endurance champion Doug Toland, who is now a full-time Honda test engineer, and Jeff Tigert, who is probably the fastest west coast club racer right now, and just so happens to have the track record at Buttonwillow on a 2004 CBR1000RR. Tigert's day job is clocking in as a full-time Honda test rider. I guess that's a good job if you're into that sort of thing—you know, riding motorcycles and getting paid to do it. Both Toland and Tigert worked extensively on the 2006 CBR1000RR not only here in the States, but in Japan, as well. Also in attendance at the test and available for questions was Noriaki Nakata. Mr. Nakata is the project manager for the 2006 CBR1000RR and is the former team manger for the Honda factory 2000-2002 MotoGP team.

I had shown up at the track for a press road test and, suddenly, following the other journalists around seemed safer then sticking your neck out to be the fast guy for the day. For all of us, our priorities eventually change. The funny thing is, test-riding the new 2006 Honda CBR1000RR actually kind of got me out of my sportbike-riding funk. With its keen mass centralization, it was just the ticket to get this old dog back up to speed. The engine revvs ultra-fast for a 1000 and the stock exhaust note growls just enough to let everybody know that something serious this way comes when you're crawling up their backside on your favorite curvy road. My immediate feeling on the bike was that Honda spent a lot of time fine-tuning the entire package on this motorcycle and all the bits work well with each other, sort of like a well-practiced symphony. The new Honda didn't immediatly strike me as the fastest bike I've ever ridden, but there's a story there. Read on.

Honda tightened up the geometry on the CBR1000RR, including new linkage in the back—--home of the Pro-Link. Together with the chassis refinements, our tester found that the new Honda features some of the best handling he'd sampled; the bike is stable yet willingly submits to mid-corner direction changes.
image by kevin wing
The chassis where this Honda excels. The CBR gives you confidence, period. Some of the other big-bores in the liter bike class seem to have a bit more kick in the pants, but it comes with instability and less faith in the bike. The CBR1000RR really got me warmed up to going faster and faster without giving me any kind of a scare. Honda has always worked hard at putting the entire package together: performance, rideability, function, and, of course, Honda reliability.

Some bikes do more in different areas, but Honda's CBR1000RR scores high marks in all areas. There are times where it does show its weight in some of the tighter turns where you're not only slowing it down, but also keeping it lifted up and still turning direction. But, in its defense, some of the slowness in steering and weighty feeling is a fair trade when it's time to drop the hammer while still heeled over and grabbing gears. A fair trade? I think so. When you need to get into a turn and change lines, it's still free enough to move about mid-turn but, at the same time, the bike remains oh-so-stable. I'm almost sure that words like stable and confidence-inspiring are probably somewhat overused in describing the CBR1000RR but, damn it, I speak the truth.

The CBR1000RR's dash is exactly what you need: the info you need to monitor frequently—redline and speed are just a flick of the eyes away. More detailed information, coolant temp, clock, tripmeter and odometer are there and easily sourced at the next stop.
image by kevin wing
The new CBR is a potent upgrade for their entry into the 1000cc sport bike class. The only thing I caution with is that the package is so good, that Honda has done almost too good of a job on it, in that it's smooth and deceptively fast. Some of the other liter bikes might offer a bit more pucker factor, whereas the CBR1000RR is so balanced and so smooth that it almost feels slow at times, until you see the world going by you like you've fallen off the planet.

This new CBR1000RR, like its predecessor, has direct lineage to the MotoGP RC211V. Its gravity die-cast aluminum frame and long swingarm rear suspension share a lot of the DNA with Honda's MotoGP bike. Sounds just like Honda PR stuff? Not at all. Without a doubt, this new CBR1000RR has to be, hands-down, the most stable and easy bike to ride in the liter-bike club. Thank God for that. I was pretty rusty from not having ridden something fairly fast in a while, and what a friend the Honda was to help me out of my funk and get my dancing shoes back on.

A re-design of the ram-air system lets more air into the airbox. The tried and true Honda dual-stage fuel injection system (44-mm throttle bodies) with two injectors per cylinder sit on the other side of the air filter.
image by kevin wing
We started the day on Bridgestone's BT-105 street-compound tires—in production half of the US allotment of CBR1000RRs will get the new Stones while the other half will receive Dunlops. I am generally not a big fan of street-compound tires used on racetracks, but I have to hand it to the 'stones, they worked pretty damn well. After lunch, the Honda techs switched us over to race-compound BT-002s, and my heart then soared with the eagles. The sticky 'stones gave me a very new appreciation for the Bridgestone radials.

Does the CBR1000RR get overshadowed by the other big bores? Is it the Ginger in a world of Mary-Anns? One look at the stats shows that its got the goods, but for whatever reason, sometimes it's the rest of the XYZ bikes that tend to get the lustful looks. Well. that's the way I felt before I rode the 2006 Honda, anyway.

Have you ever seen a movie and thought, 'Yeah, that was quite good, not my fave but really, pretty good'? Then, days afterward, you keep thinking about the film? That's really how I felt about Honda's Big Blade. Enough so, in fact, that I have almost thought, hell yes, I might need one of these to go to work on. You see, I have this really cool road about a mile from my house, and it has a bit of a drop in it. And, if I were to hit that drop in, say, third gear or so, I reckon I could pull a pretty nice power wheelie for quite some time. Hmmm....

Andy Fenwick. Soup's resident fast guy from Neenah, WI. Oh, and he helped win the hard-fought '88 WERA National endurance series with the famed--or is that infamous?—Human Race Team.
image by kevin wing

Honda has done a really fine job of refining the CBR1000RR but it's the chassis and the aesthetics that sold me, instead of the engine, and that's really saying something, because the engine is so good. The CBR1000RR has most of the goods that you'd expect on a big-bore sport bike—cassette-type close-ratio garbox, sixteen-valve cylinder head, dual-stage headlight, forged pistons, digital fuel injection with twin injectors and an ECU that provides two maps for both the fuel injection and the ignition, a stainless and titanium exhaust system—you know, the kind of tackle that fifteen years ago even Honda's GP bikes didn't offer their A-list riders. Now you get this stuff on a production sport bike for just short of $12,000.
Again, for me, it's the chassis and the aesthetic design of the bike which sells me. At speed the big CB is dead stable, and never gets its feathers fuffled, thanks to the work Honda did on the spectacular chassis.

Soup's opinion on the '06 CBR1000RR? A tremendous upgrade for an already popular liter sport bike. Tester and ex-racer Fenwick owns a bike shop and like most of us, way too many motorcycles already. His mind was haunted by the big CBR. 'Maybe if my girlfriend gets a part-time job, I can buy one ...'
image by kevin wing

I went to Buttonwillow prepared to do a job and to test a motorcycle. I honestly didn't think that this bike would affect me the way that it did.

Before I left I hoped I'd get more time on the CBR1000RR's competition, but, in the end, all I really want is more time on the CBR1000RR itself.
