Cagiva Elefant Dakar Replicas
1985
Air 4T-90 ° V-twin-cylinder engine
2x Dell'Ortello carburetor f36mm Bosch ignition
Bore / Stroke 88/61, 5 mm, 748 cc engine capacity
Rated power about 70 hp (51 kw) at 7900/min
2 Overhead camshaft with 4 valves
Ölbadkupplung; five-speed gearbox; secondary drive chain
Double-loop frame made of chrome molybdenum tubes, no underrun
Telescopic fork with 290mm travel Marzocchi 42mm f
Swingarm with 2 Öhlins spring legs, 280mm travel
Disc brakes front and rear
90/90-21 front tire size with Moouse
Rear tire size 17 "with hose
1580 mm wheelbase, 2370mm length, seat height 920mm
Dry weight of 170kg, 226kg driving with Ausrüßtung
Front tank with 60L
Maximum speed approximately 175 km / h.
1986
Two-cylinder engine with a number of 850 cc
Weber, 44er carburettors
Marzocchi fork f 41.7 mm
2 Öhlinsfederbeine
Front 90x90x21 "
Rear 140x90x18 "
1987
Two-cylinder engine with 851ccm
Weber, 44er carburettors
ca.85PS at 8000U/min
Marzocchi fork f 41.7 mm
Öhlinsfederbein
Front 90x90x21 "
Rear 140x90x18 "
1988
Two-cylinder engine with 904ccm
Weber, 44er carburettors
Marzocchi fork f 41.7 mm
Öhlinsfederbein
Front 90x90x21 "
Rear 140x90x18 "
1989
Two-cylinder engine with 904ccm
Weber, 44er carburettors
Marzocchi fork f 41.7 mm
Öhlinsfederbein
Front 90x90x21 "
Rear 140x90x18 "
1990
Two-cylinder engin
e with 944ccm
36 Kehin carburetor
80PS at 7500U/min
Marzocchi fork with 290mm f 45mm travel
Öhlinsfederbein with 290mm travel
Front 90x90x21 "
Rear 140x90x18 "
