Make Model |
Yamaha YBR 125 Cusstom |
|
Year |
2008 |
|
Engine |
Air cooled, four stroke, single cylinder, SOHC,
|
|
Capacity |
124 |
|
Bore x Stroke |
54 x 54 mm |
|
Compression Ratio |
10.0:1 |
|
Induction |
|
|
Ignition /
Starting |
CDI / electric |
|
Max Power |
10.1 hp 7.4 KW @ 7800 rrpm |
|
Max Torque |
10 Nm @ 7400 rpm |
|
Transmission /
Drive |
5 Speed / chain |
|
Frame |
Steel double cradle |
|
Front Suspension |
Telescopic forks, 120mm wheel travel |
|
Rear Suspension |
Bottom link swingarm, 105mm wheel travel |
|
Front Brakes |
Single 245mm disc |
|
Rear Brakes |
Drum |
|
Front Tyre |
90/90-M21 |
|
Rear Tyre |
90/90-M18 |
|
Wet-Weight |
106 kg |
|
Fuel Capacity |
12 Litres |
For 2008 Yamaha
introduce the YBR125 Custom, a stylish and practical model which expands the
company’s diverse 125cc line up.
The new YBR125 Custom is closely-based on the extremely popular YBR125 which
has established an enviable reputation for its quality, reliability,
simplicity, stable handling and value for money.
Custom style with affordable
practicality
With its beautiful
new bodywork and a range of special comfort-enhancing features, the YBR125
Custom is designed for the rider who is looking for a stylish, affordable
and reliable motorcycle.
The focal point of the new bodywork is the beautifully-finished 12-litre
teardrop fuel tank which gives the YBR125 Custom a distinctive look.
Matching the timeless style of the new fuel tank are deeply valanced front
and rear fenders which protect the rider from road surface dirt, and also
emphasise the ‘big-bike’ looks – and for an added touch of class the
instruments and flashers feature a brilliant chrome finish.
Also exclusive to
this new 125 custom is a stylish large-capacity muffler featuring a
chromeplated heatshield. Equipped with a highly-efficient catalyser, this
muffler ensures that the EU3- compliant YBR125 Custom is one of the quietest
and cleanest machines in the class.
For enhanced practicality and enhanced comfort a chrome-plated rear carrier
is fitted, featuring an integral grab rail.
Comfortable riding position
In addition to the
stylish new bodywork, the YBR125 Custom also features raised handlebars and
a luxuriously-padded dual seat which accentuate the bike’s handsome custom
style.
The new handlebar/seat/footrest relationship also offers a more relaxed and
upright seating position which is 20mm lower than the standard YBR125,
making this cool new 125 a comfortable daily commuter and attractive weekend
runabout.
New-style 9-spoke cast wheels
with a wide rear tyre
The new YBR125
Custom is equipped with new-style 9-spoke alloy wheels which keep unsprung
weight low for good suspension performance and easy manoeuvrability. And for
strong roadholding the new Custom is fitted with a wide section 3.50-16 rear
tyre and a 3.00-18 front tyre.
Technical highlights
-
Based on the proven and
successful YBR125
-
Custom-style teardrop fuel
tank
-
Luxuriously-padded dual seat
-
Low seat height of 760mm
(YBR125: 780mm)
-
Raised handlebars
-
Deeply-valanced front and rear
fenders
-
Large-capacity silencer with
chrome-plated heatshield
-
9-spoke cast alloy wheels
-
Chrome-plated rear carrier and
grab bar
-
Chrome-finish instruments and flashers
