Triumph Sprint GT Special Edition

.

Make Model

Triumph Sprint GT Special Edition

Year

2014

Engine

Four stroke, transverse three cylinder, DOHC, 4 valves per cylinder.

Capacity

1050 cc / 64.1 cu in
Bore x Stroke 79 x 71.4mm
Cooling System Liquid cooled
Compression Ratio 12.0:1
Lubrication Wet sump
Engine Oil Synthetic, 10W/40 Synthetic

Induction

Multipoint sequential electronic fuel injection with SAI

Ignition

Digital
Spark Plug NGK, CR9EK
Starting Electric

Max Power

96 kW / 128 hp @ 9200 rpm

Max Torque

108 Nm / 11.0 kgf-m / 80 ft-lb @ 6300 rpm

Transmission

6 Speed
Final Drive Chain
Frame Aluminium beam perimeter, swingarm single-sided, aluminium alloy with eccentric chain adjuster

Front Suspension

Showa 43mm cartridge forks with dual rate springs and adjustable preload
Front Wheel Travel 127 mm / 5.0 in

Rear Suspension

Showa monoshock with adjustable preload and rebound damping
Rear Wheel Travel 152 mm / 6.0 in

Front Brakes

2 x 320 mm Floating discs, 4 piston calipers, ABS

Rear Brakes

Single 255 mm disc, 2 piston caliper, ABS
Front Wheel Cast aluminium alloy 5-spoke 17 x 3.50 in
Rear Wheels Cast aluminium alloy 5-spoke 17 x 5.50 in

Front Tyre

120/70-ZR17

Rear Tyre

180/55-ZR17

Dimensions

Length 2260 mm / 88.9 in

Width (handlebars) 760 mm / 29.9 in

Height without mirrors 1210 mm / 47.6 in

Seat Height 815 mm / 32.1 in
Rake 23.5º
Trail 84 mm / 3.3 in
Wheelbase 1537 mm / 60.5 in

Wet Weight

265 kg / 383 lbs

Fuel Capacity

20 Litres / 5.3 US gal / 4.4 Imp gal

The 1050cc three-cylinder engine in the Sprint GT SE is long proven as one of the great motorcycle power units. Here it gives you a very healthy 130PS with a peak torque of 80ft.lb at just 6,300rpm with generous amounts well below that.

This means you get an instant response and strong acceleration without having to change down through the gears first. And the bike just pulls when the twist grip is turned, and pulls hard when it's turned far.
Configuration

The technology might be proven but it’s still thoroughly modern. We’ve included double overhead camshafts, 4 valves per cylinder and a gear-driven balance shaft to minimise vibration. The six-speed gearbox has slick and easy selection whilst the wet, multi-plate clutch is light, progressive and consistent. The fuelling is looked after by a sequential, multipoint fuel injection system and we fitted the exhaust with a catalytic converter inside the three-into-one stainless steel system.



CHASSIS
Frame
We gave the Sprint GT SE its modern twin spar aluminium design to provide you with exceptional sporting capability. The single-sided swingarm adds to that, but works just as well in the touring bike role. Its eccentric adjusters make life much easier for you when tensioning the chain.



Suspension
The suspension on the Sprint GT SE is by highly respected Japanese specialist Showa. 43mm cartridge forks complete with adjustable spring preload at the front, matched to a monoshock rear end with a generous 152mm of travel at the rear.

It has remote spring preload and rebound damping adjustability, essential on a bike that will be asked to perform the wide range of tasks that various loads and riding styles can demand.



Brakes
Braking is taken care of by 4-piston Nissin callipers at the front and a 2-piston rear calliper, supported by a sophisticated ABS system for controlled, progressive stopping power.



Tank Range
The highly fuel-efficient engine combined with the Sprint GT’s 4.4 gallon tank give you a range of well over 200 miles. Even at motorway cruising speeds and, if you keep the speed down, you could easily get over 250 miles from a tank.



Seat Height
The seat height is 815mm but it feels lower because it is narrowed at the front to make reaching the ground easier. The seat is deeply padded and carefully shaped and plays an important role in rider comfort.



Riding Position
Many years of honing the Sprint's ergonomics by our high mileage testing teams have resulted in the perfect bar-seat-footrest relationship, whatever your riding style.

We made it forward leaning enough for you to take control of the bike when riding to its capabilities, yet upright and spacious enough to provide you long distance comfort hour after hour.

Passenger accommodation was given just as much attention as yours, to ensure it’s natural and spacious and as comfortable on the back of the bike during an all-day ride as it is on the front.



FEATURES
ABS
ABS brakes are standard equipment, and the rear shock spring preload is very easily altered using the remote hand adjuster.



Fairing
The full fairing with side vent removes hot air from the engine with a neat chrome bridge. We mounted the front indicators in the mirrors and the rear ones are neatly faired-in to reduce visual clutter. While the single-sided swingarm adds to the air of class.

Functionally, the aerodynamic fairing protects you and smoothes the airflow and the front mudguard is shaped to improve the supply of cooling air to the radiator for better efficiency.



Touring Screen
The cleverly designed Touring screen, together with the fairing, takes the force out of windblast and redirects it around you and your passenger quietly and smoothly.



Instruments and Computer
As with the rest of the Sprint GT SE, the headlights, instruments and mirrors have all been refined over the years to reach today's exceptional performance. The three-dial dash featuring a clock, fuel consumption, journey time, range to empty and average speed readouts.

More storage space can be found in the right side of the cockpit and beneath the seat, where the Triumph accessory U-lock fits neatly.

We’ve even added a built-in power socket so you can charge your phone or laptop while riding.



Panniers
We designed the panniers from the outset to match the Sprint GT. So despite their large volume they fit close in at the rear and are completely integrated into the overall styling.



Luggage Capacity
The great big 31 litre, colour-coded panniers are big enough to take a large, full-face helmet - each. Add to this Triumph’s topbox, and you have a huge luggage capacity of 117 litres.
