MV Agusta Brutal 800

.

Make Model

MV Agusta Brutal 800 / ABS

Year

2015

Engine

Four stroke, transverse three cylinder. DOHC, 4 Valve per cylinder

Capacity

798 cc / 48.69 cu-in
Bore x Stroke 79 x 54.3 mm
Cooling System Liquid Cooled
Compression Ratio 13.3;1

Induction

Integrated ignition - injection system MVICS (Motor & Vehicle Integrated Control System) with three injectors Engine control unit Eldor EM2.0, throttle body full drive by wire Mikuni, pencil-coil with ion-sensing technology, control of detonation and misfire Torque control with four maps, Traction Control with eight levels of intervention

Ignition

Multipoint electronic injection
Starting Electric
Battery PERFDRfTIFinCE
Alternator 350 Wat 5000 r.p.m. 12V-8.6Ah

Max Power

92 kW / 125 hp @ 11600 rpm

Max Torque

81 Nm / 8.25 kgf-m @ 9600 rpm.
Clutch Wet, multi-disc with mechanical drive Cassette style

Transmission

6 Speed
Final Drive Chain
Gear Ratio 1st: 13/37 2nd 16/34 3rd 18/32 4th 19/30 5th 21/30 6th 22/29
Final Drive Ratio 16/41
Frame ALS Steel tubular trellis Aluminium alloy

Front Suspension

Marzocchi "UPSIDE DOWN" telescopic hydraulic fork with rebound-compression damping and spring preload external and separate adjustment 43 mm
Front Wheel Travel  125 mm / 4.9 in

Rear Suspension

Progressive Sachs, single shock absorber with rebound and compression damping and spring preload adjustment Aluminium alloy
Rear Wheel Travel  125 mm / 4.9 in

Front Brakes

2x 320mm floating discs 4 piston calipers

Rear Brakes

Single 220mm disc 2 piston caliper
Rim Front Aluminium alloy 3.50 " x 17 '
Rim Rear Aluminium alloy 5.50 " x 17 '

Front Tyre

120/65 ZR-17

Rear Tyre

180/55 ZR -17
Trail 95 mm / 3.74 in.
Dimensions  Length 2085 mm / 82.09 in
Width 725 mm -28.54 in
Wheelbase 1380 mm / 54.33 in
Seat Height 810 mm / 31.89 in
Ground Clarence 160 mm / 6.30 in

Dry Weight

167 Kg / 368.2 lbs

Fuel Capacity

16.6 Litres / 4.39 US gal
Reserve 5 Litres / 1.3 US gal

The new 800 engine offers increased power, torque and riding dynamics for the naked MV Agusta. The new adjustable suspension and the new advanced electronics package makes the Brutale 800 leader in its segment. Graphics and special colours accentuate the unmistakably lines of MV Agusta.

Brutale three-cylinder means handling, extreme agility, and absolute ease of use. Now with the new engine power and torque comparable to a 1.000cc, and with a weight of only 167 kg, the 800 Brutale offers an unique power to weight ratio. Aside from the new engine, the Brutale 800 offers a new adjustable suspension allowing the riders complete personalisation.

A dependable advanced electronics package unique within this category: MVICS (Motor & Vehicle Integrated Control System), the integrated management system of the vehicle, includes the first Full Ride by Wire with multi-map and integrated traction control. Offering optimised delivery at all engine speeds, maximum engine efficiency in terms of fuel consumption, and of course the opportunity to select different engine characteristics, choosing from the four available maps: three pre-sets, one personalised. Traction control also ensures safety and performance on any road or track surface, allowing the driver to concentrate entirely on riding. The three-cylinder engine, which debuted on the supersport F3 675, forms the basis for the technological progress in its class, thanks to exclusive technical solutions such as the counter-rotating crankshaft, used in MotoGP, but never before seen on a production bike. The frame performance is guaranteed, thanks to MV Agusta’ s unique mixed structure: the front section of steel tube trellis combined with two light aluminium alloy plates, and a sculpted single-arm rear suspension.

Brutale 800 joins Brutale 675 with its increased performance, dynamics and untouchable MV Agusta style. A motorcycle capable of satisfying the most demanding of motorcycle enthusiasts.

The characteristics
In detail, the main features of MV Agusta Brutale 800 are:

  • three-cylinder in-line engine with counter-rotating crankshaft

  • Technology MVICS (Motor & Vehicle Integrated Control System)

  • Traction control adjustable on 8 levels

  • Frame structure mixed steel trellis and aluminium plates for high torsional rigidity

  • Single-sided swingarm with adjustable rear shock absorber

  • Upside down adjustable 43mm front fork

  • Racing radial front callipers

The design
MV Agusta Brutale 800 is distinctive at first glance. A perfect combination of aesthetics, functionality, design and ergonomics. Form and substance. Unique in its kind, this three-cylinder is aligned with the standards of excellence of the Brutale 675, yet remains distinctive with new graphics and further detail enhancements. The overall compactness is visually impressive, with the mechanical components dominating; the three-cylinder engine is almost completely exposed to view, embraced by the distinctive frame and compact exhaust system. The silencer is modelled in such a way as to ensure maximum capacity and efficiency while remaining perfectly integrated. The tailpiece is essential yet elegant. Even the headlight characterises the design, by combining the original elements and stylistic features of the Brutale range. The distinctive three element exhaust pipe remains another key visual component of MV Agusta Brutale.

The engine
The new three-cylinder engine 800 has a stroke of 54.3 mm and delivers power and torque of 125 hp at 11,600 revs / min limiter at 13,000 rpm. The maximum torque is also significant touching 81 NM at 8600 rpm., The power and torque curves are strengthened and increased ensuring prompt throttle response and a generous delivery across the entire rev range. This level of performance, associated with a dry weight of 167 kg, put the Brutale 800 at the top of the category “naked” setting the new benchmark.

With F3 675 and Brutale 675 the new Brutale 800 shares most of the components. and fundamental technical choices: first, the counter-rotating crankshaft, previously used only in MotoGP is able to offer the best balance while driving, reducing inertia when changing direction and thus increasing the manoeuvrability of the vehicle.

The shell moulded crankcase employs a “closed deck” with integrated bores and features integrated circuits for both oil and water, with internal pump unit location. This reduces component numbers and offers visual cleanliness to the engine exterior. The final transmission ratio is increased, by virtue of superior performance and through the mounting of a sprocket with two teeth less.

The electronics
Brutale 675 boasts the most advanced electronic management within its category. In its succession the Brutale 800 also excels by applying advanced race technology to mass production. The system MVICS (Motor & Vehicle Integrated Control System) ensures the integrated control of the vehicle and the engine: This allows combining management of the three cylinders with the traction control, to achieve high performance with safety. Technological innovation is epitomised by the use of Full Ride By Wire. The electronic control of the throttle body, which together with the mapping for injection, and ignition optimises the air-fuel mixture at all engine speeds of delivery, maximising available power and torque as a function on request from the rider. Compared to the traditional mechanical throttle, the Full Ride By Wire allows you to untie completely the rotation of the accelerator and throttle openings, leaving the task to electronics to achieve the optimum solution offering improved efficiency and a response exceeding the expectations of the rider. Brutale 800 system uses a multimap, with three preset modes and one fully customisable so you can choose the most appropriate delivery to meet specific conditions. The integration of MVICS includes traction control on eight levels, adjustable in seconds and visible on the digital dashboard intervening throttle, ignition advance and injection.

The frame
Handling, traction, ease of use and performance: The objectives of the project were achieved by focusing on the chassis with a mixed structure. An unmistakable trademark of MV Agusta, consisting of the front section steel tube trellis and two aluminium alloy plates, fulcrum point for the long singlesided swingarm, designed to ensure the most efficient transmission of power to the asphalt.

The suspensions
Improved performance through increased levels of control and variability: The MV Agusta Brutale 800 is fitted with an upside down fork and shock absorber with hydraulic response customisable. The upside down fork 43 mm in diameter, characterised by the excellent fluidity, with an excursion of 125 mm and is adjustable in compression, rebound and spring preload. The rear shock absorber provides 119 mm stroke, adjustable in compression, rebound and spring preload.

Brutale 800, therefore, adds to the versatility of the Brutale 675 with increased suspension regulation that further enhance riding dynamics.

The brakes
Brutale 800 offers a braking system of the highest quality utilising a pair of front 320 mm diameter discs, with Brembo four-piston (32 mm diameter) radial callipers and also at the rear a high performance twin-piston (34 mm diameter) Brembo calliper, matched to a 220 mm disc.

Colours and Prices
The new Brutale 800 is available in 4 colour combinations:

  • Ruby Metallic Red/Silver

  • White/Mamba Red

  • Matt metallic Grey/Pearl White

  • White/Blue Pearl “ITALIA”
