Air cooled, four stroke, transverse four
cylinder, DOHC, 2 valves per cylinder
Capacity
603.9
Bore x Stroke
60 x 53.4 mm
Compression Ratio
9.3:1
Induction
4x 22mm Dell'Orto carbs
Ignition /
Starting
Mechanical breaker points
Max Power
60 hp @ 8700 rpm
Max Torque
37 ft-lb @ 7000 rpm
Transmission /
Drive
5 Speed / chain
Front Suspension
Telehydraulic forks
Rear Suspension
Swinging arm forks, adjustable shocks
Front Brakes
2x 265mm discs
Rear Brakes
Single 260mm disc
Front Tyre
3.25 -18
Rear Tyre
3.50 -18
Dry-Weight
190 kg
Fuel Capacity
12 Litres
