Hartford HD 125S

.

Make Model

Hartford HD 125S

Year



Engine

Four stroke, single cylinder, 2 valves per cylinder

Capacity

124 cc / 7.57 cu in
Bore x Stroke 56.5 x 49.5 mm
Compression Ratio 9.0:1
Cooling System Air cooled

Induction

Carburettor

Ignition

CDI

Starting

Electronic

Max Power

 9.5 hp / 7.1 kW @ 8200 rpm

Max Torque

 9.31 Nm / 6.9 ft. lbs @ 7500 rpm

Transmission

5 Speed
Final Drive Chain

Front Suspension

Telescopic forks

Rear Suspension

Dual shocks

Front Brakes

Single disc with 1 piston caliper

Rear Brakes

Drum

Front Tyre

2.75-18

Rear Tyre

3.50-16
Dimensions Length 1945 mm / 76.6 in
Width 815 mm / 32.1 in
Height 1110 mm / 43.7 in
Wheelbase 1280 mm / 50.4 in
Seat Height  780 mm / 30.7 in

Dry Weight

110.0 kg / 242.5 lbs

Fuel Capacity

10.3 Litres / 2.7 US gal
.
