Beta RS 390

.

Make Model

Beta RS 390

Year

2015

Engine

Four stroke, single cylinder, 4 valve

Capacity

386 cc / 23.6 cu in
Bore x Stroke  88 x 63.4 mm
Cooling System Liquid cooled
Compression Ratio 12.5:1
Lubrication Twin oil pumps with cartridge oil filter. Separate oil for engine and clutch .8 liter each

Engine Oil Capacity

0.8 L / 0.2 US gal

Induction

Keihin FCR-MX, Ø 39mm

Ignition

DC-CDI with variable ignition timing, Kokusan.
Spark Plug NGK LKAR 8A-9
Starting Electric & Kick
Clutch Wet multi-disc
Gearbox Oil Capacity 0.8 L / 0.2 US gal
Clutch Wet multi-disc

Transmission

6 Speed
Final Drive O-ring chain, DID
Primary Ratio 31:73
Frame Molybdenum steel with double cradle split above exhaust port. Quick air filter access from the side

Rake

26.5°

Front Suspension

Sachs USD fork, Ø48 mm, adjustable compression and rebound, TFX technology
Front Wheel Travel 290 mm / 11.4 in

Rear Suspension

Aluminum body Sachs shock w/adjustable rebound and hi/low speed compression
Rear Wheel Travel 290 mm / 11.4 in

Front Brakes

Single Ø 260 mm floating disc, 2 piston caliper

Rear Brakes

Single Ø 240 mm disc, 1 piston caliper

Front Tyre

90/90 -21

Rear Tyre

140/80 -18
Wheelbase 1475 mm / 58.1 in
Ground Clearance 320 mm / 12.6 in
Seat Height 934.7 mm / 36.8 in
Footrest Height 411 mm / 16.2 in

Dry Weight

110 kg / 243 lbs

Fuel Capacity

7.9 L / 2.1 US gal

Light, compact and sleek, the Beta 390 RS is an exciting dirt bike built for those who love to venture on unpaved roads.

This potent dual sport bike is propelled by a Beta-built single cylinder, 4 valve, 4 stroke, liquid cooled engine with electric start with back up kick starter. Its power is transferred to the ground by means of a six speed transmission with wet multi-disc clutch.

The motorcycle’s backbone is represented by a molybdenum steel frame which sits on a 48 mm Sachs USD fork (with adjustable compression and rebound) and a rear aluminum body Sachs shock absorber (adjustable rebound and hi/low speed compression).

Other features that are worthy of being mentioned include Voyager GPS unit, handlebar pad from Race Edition, new design seat foam and new graphics and color scheme based from the RR models.

Other features:

Trail Tech Voyager GPS unit
RR Inspired Graphics
Push-Button Seat Release
Beta-Built 4-Stroke with Electric Start
All-New Engines (2.2 lbs. lighter)
Tuck-Away Mirrors
Back-Up Kick Starter
Rear Suspension Linkage
Off-Road inspired D.O.T.Tires
Softer Seat Foam
Same Suspension as the RR Models
